4096

Terminale ad

inserimento

Terminale ad

avvitare

Dadi di

serraggio

4381

4096E

4374

10

10 x G 1/2"

G 1/2"

12

12 x G 5/8"

G 5/8"

14

14 x G 3/4"

G 3/4"

15

15 x G 3/4"

G 3/4"

16

16 x G 3/4"

G 3/4"

18

18 x G 3/4"

G 3/4"

22

22 x G 1"

G 1"

28

28 x G 1 1/4"

G 1 1/4"

35

35 x G 1 1/2"

G 1 1/2"

42

42 x G 2"

G 2"

54

54 x G 2 1/2"

G 2 1/2"

4098G

Terminale ad

inserimento

Terminale ad

avvitare

Dadi di

serraggio

4382G

4096E

4374

10 x 1/4"

1/4" x G 1/2"

10 x G 1/2"

G 1/2"

10 x 3/8"

3/8" x G 1/2"

10 x G 5/8"

G 5/8"

12 x 3/8"

3/8" x G 5/8"

12 x G 5/8"

G 5/8"

12 x 1/2"

1/2" x G 5/8"

12 x G 3/4"

G 3/4"

14 x 1/2"

1/2" x G 3/4"

14 x G 3/4"

G 3/4"

15 x 3/8"

3/8" x G 3/4"

15 x G 5/8"

G 5/8"

15 x 1/2"

1/2" x G 3/4"

15 x G 3/4"

G 3/4"

15 x 3/4"

3/4" x G 1"

15 x G 1"

G 1"

16 x 1/2"

1/2" x G 3/4"

16 x G 3/4"

G 3/4"

18 x 1/2"

1/2" x G 3/4"

18 x G 3/4"

G 3/4"

18 x 3/4"

3/4" x G 1"

18 x G 1"

G 1"

22 x 3/4"

3/4" x G 1"

22 x G 1"

G 1"

22 x 1"

1" x G 1"

22 x G 1 1/4"

G 1 1/4"

28 x 1"

1" x G 1 1/4"

28 x G 1 1/4"

G 1 1/4"

35 x 1 1/4"

1 1/4" x G 1 1/2"

35 x G 1 1/2"

G 1 1/2"

42 x 1 1/2"

1 1/2" x G 2"

45 x G 2"

G 2"

54 x 2"

2" x G 2 1/2"

54 x G 2 1/2"

G 2 1/2"

4096G

Terminale ad

inserimento

Terminale ad

avvitare

Dadi di

serraggio

4381

E4096G

4374

10 x 1/4"

10 x G 1/2"

1/4" x G 1/2"

G 1/2"

10 x 3/8"

10 x G 1/2"

3/8" x G 1/2"

G 1/2"

12 x 3/8"

12 x G 5/8"

3/8" x G 5/8"

G 5/8"

12 x 1/2"

12 x G 5/8"

1/2" x G 5/8"

G 5/8"

14 x 1/2"

14 x G 3/4"

1/2" x G 3/4"

G 3/4"

15 x 3/8"

15 x G 3/4"

3/8" x G 3/4"

G 3/4"

15 x 1/2"

15 x G 3/4"

1/2" x G 3/4"

G 3/4"

16 x 1/2"

16 x G 3/4"

1/2" x G 3/4"

G 3/4"

18 x 1/2"

18 x G 3/4"

1/2" x G 3/4"

G 3/4"

18 x 3/4"

18 x G 1"

3/4" x G 1"

G 1"

22 x 3/4"

22 x G 1"

3/4" x G 1"

G 1"

22 x 1"

22 x G 1"

1" x G 1"

G 1"

28 x 1"

28 x G 1 1/4"

1" x G 1 1/4"

G 1 1/4"

35 x 1 1/4"

35 x G 1 1/2"

1 1/4" x G 1 1/2"

G 1 1/2"

42 x 1 1/2"

45 x G 2"

1 1/2" x G 2"

G 2"

54 x 2"

54 x G 2 1/2"

2" x G 2 1/2"

G 2 1/2"

4330

Terminale ad

inserimento

Terminale ad

avvitare

Dadi di

serraggio

4372

4370

4374

8

8 x G 3/8"

G 3/8"

10

10 x G 1/2"

G 1/2"

12

12 x G 5/8"

G 5/8"

15

15 x G 3/4"

G 3/4"

16

16 x G 3/4"

G 3/4"

18

18 x G 3/4"

G 3/4"

22

22 x G 1"

G 1"

28

28 x G 1 1/4"

G 1 1/4"

35

35 x G 1 1/2"

G 1 1/2"

42

42 x G 2"

G 2"

54

54 x G 2 1/2"

G 2 1/2"

6.0 Assemblaggio dei singoli componenti

I collegamenti

filettati a tenuta piana vengono forniti con guarnizioni resistenti a tutti i tipi di gas
