42
Valves
Valves
ECOLINE PTF 800
Class
NPS [inch]
T [°C]
SICCA 150-4500 PCF
Class
NPS [inch]
T [°C]
Lift check valves for nuclear applications
NUCA/-A/-ES, Type V
RJN
RYN
PN
DN
T [°C]
PN
DN
T [°C]
PN
DN
T [°C]
≤ 410
10 - 50
≥ -29 - ≤ +365
≤ 140
80 - 600
≥ -29 - ≤ +300
≤ 210
65 - 300
≥ -29 - ≤ +365
Description
Lift check valve for nuclear applications, with butt weld ends, replaceable seat
(NUCA-ES), straight-way pattern, made of steel or stainless steel.
Applications
Feed water and live steam systems.
http://shop.ksb.com/catalog/k0/en/product/ES000455
Description
Damped lift check valve with butt weld ends, for nuclear applications, individually
selectable damping characteristic, made of steel or stainless steel.
Applications
Feed water and live steam systems.
http://shop.ksb.com/catalog/k0/en/product/ES000459
Description
Combined lift check/shut-off valve with butt weld ends, for nuclear applications, Y-
pattern, with gland packing or bellows, made of steel or stainless steel.
Applications
Feed water and live steam systems.
http://shop.ksb.com/catalog/k0/en/product/ES000333
Not available for worldwide sale
Actuator/Automation
800
1⁄2 - 2
≥ 0 - ≤ +593
150 - 4500
1⁄4 - 21⁄2
≥ 0 - ≤ +816
Description
Lift check valve to ANSI/ASME with threaded sockets (NPT), butt weld ends (BW) or
socket weld ends (SW), Trim 8 (Stellite/13 % chrome steel), with bolted cover,
spring-loaded valve disc, available in carbon steel and alloy steel.
Applications
Industrial plants, power stations, process engineering, refineries, oil and marine
applications; for water, steam, gas, oil and other non-aggressive fluids.
http://shop.ksb.com/catalog/k0/en/product/ES000374
Description
Lift check valve to ANSI/ASME with NPT (F) threaded ends or socket weld ends,
with spring-loaded valve disc, integral flange with bolted cover (Class 800) or
welded cover (Class 1500/2500/4500), Stellite hard-faced body seat, disc seating
face made of Stellite hard-faced 13 % chrome steel, with graphite gasket.
Available in carbon steel and alloy steel.
Applications
Refineries, power stations, general industry and process engineering. For water,
steam, oil, gas and non-aggressive fluids. Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000481
