Climatizzazione Gli Invisibili - Air conditioning The Invisibles

UNITÀ INTERNE INDOOR UNITS

ELFO E IDRA

SPLIT A PARETE

Wall mounted

EVOLVE

WI-FI

SWING

ORIZZONTALE

VERTICALE

Evolve è la nuova unità a parete sviluppata da Tekno Point per chi

ricerca un'estetica più elegante e dal design innovativo oltre a contenuti

tecnologici di ultima generazione.

In tutte le unità il modulo wi-

fi

è già incluso e da subito collegabile

con l'App Smart Life. Integrati troviamo inoltre sia il

filtro al plasma che

il nuovissimo sistema di sterilizzazione UVC. Grazie alla sua lampada

LED a ultravioletti permette la disinfezione dinamica della batteria,

senza la produzione di ozono e ioni negativi, consentendo comunque

l'eliminazione di virus e batteri puri

ficando così l'ambiente.

Il rivoluzionario

flap forellato consente di sfruttare "l'effetto Venturi"

per una distribuzione ottimale dell'aria in uscita ottenendo il massimo

comfort disponibile per la categoria. Sfruttando sia le centinaia

di microfori presenti sul flap principale che l'aletta interna ondulata,

anch'essa provvista di microfori, viene prodotta

una sensazione di brezza il più simile possibile a quella naturale.

Regolazione flap orizzontale da telecomando.

Evolve is the new wall-mounted unit developed by Tekno Point for

those seeking a more elegant aesthetic and innovative design in

addition to the latest technological content.

In all units the wi-fi module is already included and immediately

connectable with the Smart Life App. Also integrated we

find both the

plasma

filter and the brand new UVC sterilization system. Thanks to

its ultraviolet LED lamp it allows dynamic disinfection of the battery,

without the production of ozone and negative ions, while still allowing

the elimination of viruses and bacteria thus purifying the room.

The revolutionary microporous air louver allows the "Venturi effect" to

be exploited for optimal distribution of the outgoing air, achieving the

highest comfort available for the category. By taking advantage of both

the hundreds of micro-holes on the main air louver and the second

corrugated inner air louver, which also has micro-holes, a breezy

feeling as close as possible to the natural one is produced.

Automatic horizontal

flap.

Filtro al plasma

e sistema di sterilizzazione UVC

Plasma

filter

and UVC sterilization system

Aletta interna

ondulata

Corrugated inner

air louver

Flap forellato

Air louver

Unit

à interna a parete - Wall-mounted indoor unit

Codice - Code

-

EVO-09 (I)

EVO-12 (I)

Alimentazione - Power Supply

V-Hz-Ph

230-50-1

230-50-1

Raffreddamento

Cooling

Potenza

Capacity

Nominale - Nominal

W/BTU

2600/8900

3500/11900

Riscaldamento

Heating

Potenza

Capacity

Nominale - Nominal

W/BTU

2800/9600

3650/12500

Portata d’aria - Air

flow

m

3

/h

700/650/600/500

700/650/600/500

Pressione sonora - Sound level (SHi, Hi, Med, Lo, Quiet)

dB(A)

43/39/30/25/18

43/39/30/25/18

Potenza sonora - Sound power (SHi, Hi, Med, Lo, Quiet)

dB(A)

54/50/41/36/29

54/50/41/36/29

Dimensioni - Dimensions (LxPxH)

mm

896 x 192 x 295

896 x 192 x 295

Peso - Weight

Kg

10,5

10,5

Tubazioni frigorifere

Refrigeration piping

Dimensioni - Dimensions

inch

1/4”-3/8”

1/4”-3/8”

Temperatura impostabile

Set temperature range

Ambiente interno (raffr/risc) - Indoor (heat/cool)

°C

+16~+31

+16~+31
