Pumps

Pumps

ILNC

Control unit

ILNR

Megaline

33

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

n [rpm]

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

32 - 125

≤ 370

≤ 112

≤ 16

≥ -20 - ≤ +70

≤ 3000

Data for 50 Hz operation

Also available for 60 Hz

150 - 350

≤ 1600

≤ 93

≤ 10

≥ -15 - ≤ +70

≤ 1450

Data for 50 Hz operation

Also available for 60 Hz

32 - 200

≤ 600

≤ 135

≤ 16

≥ 0 - ≤ +90

Data for 60 Hz operation

Description

Vertical close-coupled centrifugal pump in in-line design, with electric motor,

closed impeller and mechanical seal. ILNCS fitted with an auxiliary vacuum

pump, ILNCE with ejector. Standardised IEC frame motor. ATEX-compliant

version available.

Applications

Hot-water heating systems, cooling circuits, air-conditioning systems, marine

applications, water and service water supply systems, cleaning systems and

industrial recirculation systems

http://shop.ksb.com/catalog/k0/en/product/ES000731

Description

Vertical volute casing pump in in-line design, single-stage, with closed single-

entry impeller. Equipped with replaceable casing wear rings in pump casing

and casing cover. ILNR with flexible coupling.

Applications

Marine applications, cargo tank cleaning, scrubbers, brine circulation, ballast

water, bilge water

Description

Volute casing pump for horizontal or vertical installation, in back pull-out

design, single-stage, radially split volute casing, replaceable casing wear rings.

Volute casing in in-line design with closed radial impeller, with multiply

curved vanes, single mechanical seal to EN 12756.

Applications

Heating circuits, water supply systems, air-conditioning systems, waste water,

industrial recirculation systems

http://www.ksb.com.br/ksb-br-pt/pesquisa.php?_q=megaline

Standardised / close-coupled pumps

Etanorm

DN

Q [m

3

/h]

H [m]

p [bar]

T [°C]

25 - 150

≤ 640

≤ 160

≤ 16

≥ -30 - ≤ +140

Data for 50 Hz operation

Also available for 60 Hz

Description

Horizontal volute casing pump, single-stage, with ratings and main

dimensions to EN 733, long-coupled, back pull-out design, with replaceable

shaft sleeves / shaft protecting sleeves and casing wear rings, with motor-

mounted variable speed system. With KSB SuPremE, a magnetless

synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with

1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to

IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB

PumpDrive 2 Eco variable speed system without rotor position sensors. Motor

mounting points in accordance with EN 50347, envelope dimensions in

accordance with DIN V 42673 (07-2011). ATEX-compliant version available.

Applications

Pumping clean or aggressive liquids not chemically or mechanically aggressive

to the pump materials in water supply systems, cooling circuits, swimming

pools, fire-fighting systems, irrigation systems, drainage systems, heating

systems, air-conditioning systems, spray irrigation systems

http://shop.ksb.com/catalog/k0/en/product/ES000062
