Sistema a cartellare

Flanging system

Dadi in ottone nichelato a sede speciale con filettatura femmina ISO 228 G a battuta piana e

guarnizioni piane KLINGERSIL C4324 a base di fibre sintetiche idonee al trasporto di acqua

potabile e resistenti a temperature operative continue di 250°C (liquidi) e 200°C (vapori)

Nickel plated brass nuts with special seat and ISO 228 G female thread with synthetic fibers

based KLINGERSIL C4324 plane gaskets for drinking water and resistant to continuous

working temperatures up to 250°C (liquids) and 200°C (vapours)

Codice

Code

DN

Fil. connessione

Connection thread

Pz./conf.

Pcs./pack

€/confez.

€/pack

€/Pz.

€/Pcs

Conf./box

Packs/box

A02-0010-

00725

15

G 3/4"

10

10

A02-0010-

00726

20

G 1"

10

-

A02-0010-

00727

25

G 1" 1/4

10

-

Codice

Code

DN

Fil. connessione

Connection thread

Pz./conf.

Pcs./pack

€/confez.

€/pack

€/Pz.

€/Pcs

Conf./box

Packs/box

A02-0010-

00731

12

G 3/4"

10

-

A02-0010-

00732

15

G 1"

10

-

A02-0010-01893

20

Dadi ridotti in ottone nichelato a sede speciale con

filettatura femmina ISO 228 G a battuta

piana e guarnizioni piane CENTELLEN WS 3820 a base di fibre aramidiche idonee al trasporto

di acqua potabile e resistenti a temperature operative continue di 200°C

Nickel plated brass reduced nuts with special seat and ISO 228 G female thread with arammidic

fibers based CENTELLEN WS 3820 plane gaskets for drinking water and resistant to continuous

working temperatures up to 200°C

G 1" 1/4

10

-

Sistemi di tubazioni per impianti solari-termici / Tubing systems for thermal-solar installations 101
