Code
Capacity
Max
press.
Connection
Dimensions
Packaging
Qty/
pallet
L. bar inch
mm
m3
n.
S202436CS405Y000
24
10
1”
351x347
0.045
54
US06036CS405Y000
60
10
1”
379X815
0.131
15
US10036CS405Y000
100
10
1”
450X910
0.200
15
S2H2036CS40BP05Y
20
10
1”
351X358
0.045
54
US06136CS405Y000
60
10
1”
410X670
0.114
20
US10136CS405Y000
100
10
1”
485X756
0.183
15
MADE IN ITALY
ULTRAVARE
M
LS
•
Pressure tank
•
Capacity20
-
24
-
60
-
100L.
•
Reinforced butyl membrane
•
S/s flange
•
White polyester pain��ng
•
Maximum pressure 10 bar
•
Precharge 2 bar
FEATURES
Top quality product
High corrosion resistance
Increased plate thickness
Suitable for very aggressive environments
High strength coa��ng
5
YEAR
W
ARRANTY
via del Santo, 207
—
35010 Limena (PD) ITALY
—
ph. +39 049 8840322
—
fax +39 049 8841399
—
www.varem.com
