PS4001G

Curva a 90° F/filetto M

Codice

Dimensione

L

L1

Z

Z1

S

PS4001G0150400

15 x 1/2"

46

47

24

34

22

PS4001G0180400

18 x 1/2"

50

52

28

39

22

PS4001G0180600

18 x 3/4"

50

54

28

39

28

PS4001G0220600

22 x 3/4"

55

56

32

41

28

PS4001G0280800

28 x 1"

66

66

42

49

36

PS4001G0351000

35 x 1 1/4"

78

78

51

59

43

PS4001G0421200

42 x 1 1/2"

100

86

64

67

50

PS4001G0541600

54 x 2"

120

107

79

83

62

PS4002G

Curva a 90° F/filetto F

Codice

Dimensione

L

L1

Z

Z1

S

PS4002G0150400

15 x 1/2"

46

43

24

28

26

PS4002G0180400

18 x 1/2"

50

46

28

31

26

PS4002G0180600

18 x 3/4"

50

48

28

32

31

PS4002G0220600

22 x 3/4"

55

53

32

36

31

PS4002G0280800

28 x 1"

66

66

42

47

39

PS4002G0351000

35 x 1 1/4"

78

79

51

57

48

PS4002G0421200

42 x 1 1/4"

100

88

64

67

55

PS4002G0541600

54 x 2"

120

107

79

81

67

15

PS4090G

Gomito a 90° F/filetto F

Codice

Dimensione

L

L1

Z1

Z

S

PS4090G0150400

15 x 1/2"

46

30

24

15

26

PS4090G0180400

18 x 1/2"

46

30

24

15

26

PS4090G0220400

22 x 1/2"

47

30

24

15

26

PS4090G0220600

22 x 3/4"

56

36

33

20

31

PS4090G0280800

28 x 1"

56

43

32

23

39

PS4090G0351000

35 x 1 1/4"

66

49

39

28

48

* Tutte le misure sopra riportate sono in mm, se non diversamente specificato.
