FOR UNDERGROUND INSTALLATION

MODULES AND CONTROL UNITS FOR “RAIN BASIC” SYSTEMS

Management and control systems

The command unit controls and manages the entire system, guaranteeing continuous operation in total safety.

You can choose between three different management and distribution systems of the rainwater: the S model (base), the F model (advanced)

and the PX model with a stainless steel submersible pump.

MODEL “S” and “F” CONTROL UNIT with self-priming pump

CONTROL UNIT

Code

Vacuum weight

(kg)

Weight in operation

(kg)

Height

Width

Depth

S

L3A0000

18

33

718

650

260

Warning: the control unit must be installed inside the home, in an enclosed, covered and dry place.

CONTROL UNITS COMPLY WITH EUROPEAN STANDARD EN 1717

“PX” SUBMERSIBLE PUMP UNIT

F

L3A0010

20

35

850

750

290

Module

Code

Panel height

Panel width

Panel depth

PX

L3A0020

718

650

260

The PX unit is composed of a stainless steel submersible pump, a safety device, an intake pipe (L. 2.5 m; ø 1”) and a cable gland M16.
