KESSEL AG

Catalogue EN 4.1

3.2

Pumping stations 161

Accessories

Outdoor control cabinet

for installation of control units, modems, heating element, warning beacon outside of buildings

Height over all

in mm

1740

1740

1740

1790

Width / depth

in mm

460/320

590/320

785/320

1115/320

Art. no.

97 716

97 714

97 723

97 724

for control unit,

heating, warning

beacon

for heating and

pressure pipe

for control unit,

modem, heating,

warning beacon

for control unit,

modem, heating,

warning beacon

and pressure pipe

Height over ground level: 870 mm

Height over ground level: 870 mm

Height over ground level: 870 mm

Height over ground level: 870 mm

460

Note: Preassembled version on request

Outdoor control cabinet

preassembled version; with factory-mounted system components; outdoor pillar cabinet

3.2

Material: Glass-fibre reinforced polyester

Version includes:

• standard cabinet with profiled surface

• open floor

• three-point locking with swivel handle

• with Euro lock cylinder

• door opening angle 180°

Protection rating: IP44

Colour: RAL 7035

Illustration shows Example for Aqualift S/F

Illustration shows Example for Ecolift XL

ground level

1

8

4

7

P

u

m

p

i

n

g

s

t

a

t

i

o

n

s

c

a

.

9

2

0

m

a

x

.

6

0

0

m

i

n

.

3

0

0

8

7

0

1115

290

351
