172 3.3 Warning / control units

Accessories

Control unit accessories

Catalogue EN 4.1

KESSEL AG

Art. no.

20 162

80 072

80 074

Art. no.

20 222

20 223

20 224

Art. no.

80 893

Art. no.

28 785

Audible alarm

Potential-free contact

Alarm unit

with electrode probe

with optical probe

Compatibility: For all warning- and control units

Cable length: 20 m

Compatibility: For all control units 230 V;

not for warning devices Art. no. 20 222 and 20 223

Compatibility: For warning devices Art. no. 20 222

and 20 223

Function: For monitoring and reporting of flooding;

for conductive liquids

Inclusive: Visual and audible alarm warning, battery

back up, with Logbook, connection for remote alarm

speaks (Art. no. 20 162) or upgradable with

potential free contact.

Voltage: 230 V ~ 50 Hz (IP 54)

Plug: 2 pin grounded

Cable length: 5 m (extendable up to 30 m)

Function: For monitoring and reporting of flooding;

for conductive / non-conductive liquids

Inclusive: Visual and audible alarm warning, battery

back up, with Logbook, connection for remote alarm

speaks (Art. no. 20 162) or upgradable with

potential free contact.

Voltage: 230 V ~ 50 Hz (IP 54)

Plug: 2 pin grounded

Cable length: 5 m (extendable up to 30 m)

Cable length: 10 m (extendable up to 30 m)

Compatibility: For connection to pump/probe cables

for connection to the coded connectors from

Art.no.28731/28746

152

152

1

4

5

6

8

1

4

5

6

8

Connector set

Connector set

USB housing socket

USB housing socket

Compatibility: For routing the USB connection

to the outside of the housing.

For 230 Volt Comfort control units Mono/Duo
