RACCORDI A COMPRESSIONE PER GAS CON OGIVA IN OTTONE

Codice

Tipo

Prezzo € Cat.

Conf.

Codice

Tipo

Prezzo €

Cat. Conf.

Code

Size

115 0054

12

115 0047

15

115 0052

18

115 0049

22

115 0055

28

Price €

Cat.

Unit/Box

Code

Size

Price €

Cat.

Unit/Box

COMPRESSION FITTINGS WITH BRASS RING FOR GAS

ISTRUZIONI PER IL CORRETTO MONTAGGIO - SERIE 1150

1150 SERIES - INSTRUCTIONS FOR THE CORRECT ASSEMBLING

TAGLIO DEL TUBO

PIPE CUTTING

È consigliabile eseguire il taglio del tubo rame con appositi strumenti

che consentono un taglio senza bave e perfettamente perpendicolare

all’asse del tubo.

Use the appropriate instruments which allow a precise cut,

perpendicular and without any trimming.

Clear the pipe carefully in order to remove any remaining trimming.

For soft copper pipe use pipe support art. 1116

Put the nut and the ring on the pipe. Tighten the nut by hand as

much as possible then use a key following the above table.

N.B.: It is necessary to lubricate the ring with potable oil or grease

to allow a more uniform and plastic strain and make easier the

assembly

SBAVATURA E PULITURA DEL TUBO

PIPE CLEANING

Sbavare bene il tubo e pulirlo per eliminare eventuali trucioli residui.

Utilizzando tubo in rame ricotto usare la bussola di rinforzo art. 1116

ASSEMBLING FITTING

MONTAGGIO DEL RACCORDO

Infilare dado e ogiva sul tubo. Avvitare il dado a mano per quanto

consentito, poi in base alla misura del tubo rame chiudere con chiave

come da tabella.

N.B.: Al fine di assicurare una maggiore facilità di montaggio ed una

miglior tenuta è consigliabile lubrificare le ogive con olio o grasso,

idoneo per acqua potabile.

1162

1161

Dado

Ogiva in CW508L

Nut

CW508L brass ring

C04

C04

C04

C04

C04

10/600

50/350

25/300

10/160

10/100

115 0051

12

115 0030

15

115 0048

18

115 0046

22

115 0053

28

C04

50/3500

C04

50/2000

C04

50/1500

C04

50/1000

C04

50/700

12

15

18

22

28

G 3/8”

G 1/2”

M24 x 1,5

W 1”1/8 x 1/14

W 1”3/8 x 1/14

12

15

18

22

28

1

1

1

1

3/4

B

A

TABELLA FILETTATURE/ THREADS TABLE

A

B

TABELLA DI SERRAGGIO DADO n° giri/ NUT TIGHTENING TABLE - n° turns

A

N° Giri/ Turns
