“COBRAPEX OXISTOP” CROSS-LINKED POLYETHYENE PIPE WITH ANTI-OXIGEN BARRIER

TUBO IN POLIETILENE RETICOLATO CON BARRIERA ANTI-OSSIGENO “COBRAPEX OXISTOP”

Ad alta flessibilit

à per impianti sfilabili - guaina corrugata

High-flexibility for sliding systems - plastic corrugated sheath

Codice

Code

Tipo

Size

Prezzo €/m

Price €/m

Cat.

Cat.

Conf.

Unit/Box

Codice

Code

Tipo

Size

Ø est. guaina

Ø out sheath

Prezzo €/m

Price €/m

Cat.

Cat.

Conf.

Unit/Box

Codice

Code

Tipo

Size

Prezzo €/m

Price €/m

Cat.

Cat.

Conf. (m)

Unit/Box (m)

Codice

Code

Tipo

Size

Ø est. guaina

Ø out sheath

Prezzo €/m

Price €/m

Cat.

Cat.

Conf. (m)

Unit/Box (m)

GUIDA ALLA SCELTA RACCORDERIA TIEMME

TIEMME FITTINGS CHOOSING GUIDE

Raccordi a compressione per tubo Pex “COBRAPEX” - serie 1400

Cap. 7

Cap. 8

Cap. 14

Compression fittings for Pex pipe “COBRAPEX” - 1400 series

Raccordi a pressare per tubo Pex “COBRAPEX“ - serie 1700

Press-fittings for Pex pipe “COBRAPEX“ - 1700 series

Raccordi a pressatura assiale “ASSIALPEX“ per tubo Pex “COBRAPEX“ - serie 3430

“ASSIALPEX“ Axial press fittings for Pex pipe “COBRAPEX“ - 3430 series

ISTRUZIONI PER IL TAGLIO DEL TUBO

INSTRUCTIONS FOR CUTTING THE PIPE

Per ottenere una perfetta giunzione, indipendentemente dal tipo di

raccordo che verr

à in seguito utilizzato, si devono eseguire alcune

semplici ma importanti operazioni per la preparazione del tubo.

Procedere al taglio del tubo nella misura desiderata. Per effettuare

il taglio è consigliabile utilizzare un tagliatubi o l’apposita cesoia,

facendo in modo che il taglio sia il più perpendicolare possibile

rispetto all’asse del tubo stesso (Fig.1).

In order to achieve a perfect connection it is necessary to follow the

simple and basic procedures indicated below:

Cut the pipe to the desired size by using a pipe-cutter, making sure

that pipe cutting is perpendicular to pipe axis (fig. 1).

FIG. 1

0805B

0900B

Tubo in polietilene reticolato ad

alta flessibilit

à con barriera anti-

ossigeno in rotoli con guaina blu

Guaina corrugata blu per la

protezione del tubo

colore tubo/ pipe color

colore guaina/ sheath color

High flexibility cross-linked

polyethylene pipe with anti-

oxigen barrier rolls with blue

corrugated sheath

C17 50/1350

C17 100/1200

090 0004

090 0010

090 0003

090 0008

090 0005

090 0001

090 0002

090 0007

Corrugated blue sheath for

protection of the pipe

C17 100/2800

C17 50/1400

C17 100/2800

C17 50/1000

024 0003

024 0002

colore tubo/ pipe color

colore guaina/ sheath color

Ø int.=19 mm

Ø int.=23 mm

Ø int.=23 mm

Ø int.=28 mm

Ø int.=19 mm

Ø int.=23 mm

Ø int.=23 mm

Ø int.=28 mm

16 x 2,0 28

16 x 2,0 24,5

0805R

0900R

024 0004

024 0001

16 x 2,0 28

16 x 2,0 24,5

Corrugated red sheath for

protection of the pipe

C17 100/2800

C17 50/1400

C17 100/2800

C17 50/1000

Tubo in polietilene reticolato ad

alta flessibilit

à con barriera anti-

ossigeno in rotoli con guaina

rossa

High flexibility cross-linked

polyethylene pipe with anti-

oxigen barrier rolls with red

corrugated sheath

C17 50/1350

C17 100/1200

Guaina corrugata rossa per la

protezione del tubo

309
