COLLETTORI DI DISTRIBUZIONE “LINEARE”

“LINEARE” DISTRIBUTION MANIFOLDS

Utilizzabili con cassetta 1810, 1812, 1910P, 1920-1930 e 1939-1940 (pag. 353)

Use with box 1810, 1812, 1910P, 1920-1930 and 1939-1940 (pag. 353)

1897K

GUIDA ALLE CONNESSIONI

CONNECTION GUIDE

24x19 fil.

16

1632K

For copper pipe

Per tubo multistrato

For multilayer pipe

1245K

Per tubo rame

1897K

Collettore “LINEARE“ in ottone

CW617N cromato, con interasse

36 mm e uscite 24x19 fil Ø (16).

Filetto fasato con pretenuta.

“LINEARE” manifold made of

CW617N chromed-plated brass,

Distance between centres 36

mm with 24x19 tpi Ø (16). Self-

seal thread with o-ring.

24x19 fil.

16

Codice

Mandata N.vie

Uscite

Prezzo €

Cat. Conf.

FILETTATURA MASCHIO/FEMMINA FASATA

MALE/FEMALE SELF-SEAL THREAD

Code

Delivery Ways

Outlets

Price €

Cat. Unit/Box

191 0452

191 0453

191 0454

191 0455

191 0456

191 0457

191 0458

191 0459

3/4”G

2

3/4”G

3

3/4”G

4

3/4”G

5

1”G

2

1”G

3

1”G

4

1”G

5

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

24 x 19 fil (ø16)

C18 1/50

C18 1/40

C18 1/30

C18 1/25

C18 1/50

C18 1/40

C18 1/30

C18 1/25

Per tabella giri di serraggio vedi fine del capitolo

Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24

For nut tightenings table see end of chapter

For brackets and boxes see the paragraph “Mounting guide“ cap. 24
