GRUPPI DI MISCELAZIONE E DISTRIBUZIONE REGOLAZIONE PUNTO FISSO - 1”

MIXING UNITS WITH MANIFOLDS THERMOSTATIC THERMAL REGULATION - 1”

3896PF - 3896PFBYD - 3896PFHT - 3896PFHTBYD

DESCRIZIONE

DESCRIPTION

Gruppo di miscelazione e distribuzione per impianti radianti premontato in

armadietto metallico composto da:

• Kit di miscelazione con regolazione punto fisso

• Pompa di circolazione ad alta efficienza (EEI 0,23) con velocit

à variabile e

magneti permanenti.

• Collettore di mandata modulare completo con regolazione di flusso a

mezzo flussimetri con derivazioni 3/4”x18 (Eurocono)

• Collettore di ritorno modulare con valvole di intercettazione

termostatizzabili con derivazioni 3/4”x18 (Eurocono)

• Valvola sfogo aria e valvola di carico/scarico

• Disponibili modelli con by-pass e kit alta temperatura 3 vie per radiatori

Mixing unit for underfloor heating systems, pre-assembled in metallic box,

consisting of:

• Mixing unit with thermostatic thermal regulation

• High efficiency pump (EEI 0,23) with variable speed and permanent

magnets.

• Supply manifold provided with flow meters and 3/4”x18 outputs

(Euroconus)

• Return manifold with manual thermostatic valves (option for thermal

actuators) and 3/4”x18 outputs (Euroconus)

• Air vent and drain ball valve

• Available with by-pass and 3 ways manifold for radiator system

VERSIONE CON COLLETTORE

ALTA TEMPERATURA

KIT MANIFOLD FOR RADIATOR

SYSTEM VERSION

VERSIONE CON BY-PASS

DIFFERENZIALE

DIFFERENTIAL BY-PASS VERSION

436

DIMENSIONI

DIMENSIONS

N. vie/ n° ways

L (mm)

2

3

4

5

6

7

8

9 10 11

12

600

700

850

1000

1200

50 50

70

2

0

0

0

÷

1

1

0

6

7

0

50 50

L

120÷170
