CONTO TERMICO

INSERTI

Per maggiori informazioni

consultare il nostro sito:

www.lanordica-extraflame.com

COMFORT PLUS CRYSTAL

(Canalizzato)

A

+

| 3,2-11,0 kW-N | 315 m

3

PLUS

DN9-P-027

• Mando a distancia

• Pantalla Tàctil

• Canalización hasta 6 metros a través

de una salida posterior Ø80 (se puede

termostatizar)

• Canalización con motor independiente

CANALIZZAZIONE

• Ventilazione forzata

• Focolare in ghisa estraibile

• Scambiatore di calore con sistema di

pulizia manuale

• Termostato di sicurezza

• Termostato interno

• Predisposizione per termostato esterno (TA)

• Cronotermostato settimanale

• Telecomando

• Console touch screen

• Canalizzazione fino a 6 metri tramite 1

uscita posteriore Ø80 (termostatabile)

• Canalizzazione con motore dedicato

• Convection fan

• Extractable cast iron hearth

• Heat exchanger with manual cleaning

system

• Over heating Thermostat

• Internal thermostat

• Foreseen for external thermostat (TA)

• Weekly chronothermostat

• Remote Control

• Touch screen console

• Ducting system till 6 mt. thanks to 1 rear

outlet Ø80 (thermostatable)

• Ducting system with dedicated motor

• Ventilation air chaud

• Foyer en fonte amovible

• Echangeurs de chaleur système de

nettoyage manuel

• Thermostat de sécurité

• Thermostat intérieur

TELECOMANDO

Telecomando a 9 tasti

9-key remote control

Télécommande à 9 touches

Fernbedienung mit 9 Tasten

Mando a distancia de 9 teclas

DATI TECNICI

702x576x673

170

(kg-l) ~16 - ~25

100 - 130

• Prédisposition pour thermostat extérieur

(TA)

• Chronothermostat hebdomadaire

• Télécommande

• Console tactile

• Canalisation jusqu’à 6 mt. à travers 1

sortie postérieure Ø80 (thermostatable)

• Système de canalisation avec ventilateur

dediée

• Sekundärluft

• Ausziehbarer Feuerraum aus Gusseisen

• Manuelle Reinigung des Wärmetauschers

• Sicherheitsthermostat

• Interner Thermostat

• Anschluss für externen Raumthermostat

(potentialfreier Anschluss)

• Thermostat für die wöchentliche

Programmierung

• Fernbedienung

• Touchscreen-Konsole

• Kanalisierung bis 6 mt. durch 1 hinteren

Ausgang Ø80 (durch Thermostat regelbar)

• Kanalisierung mit eigenem Lüfter

• Ventilación forzada

• Hogar en fundición extraíble

• Intercambiador de calor con sistema de

limpieza manual

• Termostato de seguridad

• Termostato interno

• Posibilidad de conexion de termostato

externo (TA)

• Cronotermostato semanal

OPTIONAL

Modulo WiFi “Etichetta bianca”

(App “Total Control”)

Wi-Fi module “White label”

(App “Total Control”)

Module WI-FI “Etiquette Blanche”

(App “Total Control”)

WI-FI-Modul “Weisses etikett”

(App “Total Control”)

Módulo Wi-Fi “Etiqueta blanca”

(App Total Control)

TECNOLOGIA

OPTIONAL

DIMENSIONI

Cassetto caricamento pellet frontale

(optional)

Frontal pellet feeding drawer (optional)

Tiroir alimentation pellet frontal

(optionnel)

Vordere Pelletsbefüllungsschublade

(auf Anfrage)

Cajón cargamento pellet frontal

(optional)

CERTIFICAZIONI

15a B-VG

BlmSchV

Dimensioni con cornice: 820x644x673

Dimensions, frame included: 820x644x673

Dimensions avec cadre: 820x644x673

Abmessungen (Rahmen inbegriffen): 820x644x673

Dimensiones con marco: 820x644x673

(min-max) 96,1 - 90,8

0,7 - 2,5

80

58

59
