ENERGY LABEL

A partire dal 1 Gennaio 2018 è in vigore l’etichettatura energetica

anche per tutti i generatori di calore per il riscaldamento a biomassa

con o senza la produzione di acqua calda. Questa indicazione, basata

su direttive e regolamenti dell’Unione Europea, assegna una classe di

merito (da G ad A++) e consente ai clienti scelte informate sulla base

dei consumi e dell'efficienza.

From 1st January 2018 the Energy Labelling Regulation comes into

force also for all the biomass heating appliances, both roomheater

appliances and appliances designed to heat the water for central he-

ating and domestic hot water. This directive, in accordance with the

regulations of the European Union, will assign an Energy Efficiency

Class (from G up to A++) providing the buyers with information about

the consumption and the efficiency

A partir du 1er Janvier 2018, l'étiquetage énergétique est en vigueur

également pour tous les générateurs de chaleur pour le chauffa-

ge de la biomasse avec ou sans la production d'eau chaude. Cette

LEGENDA

Legend / Légende / Zeichenerklärung / Leyenda

DATI TECNICI / TECHNICAL DATA / DONNÉES TECHNIQUES / TECHNISCHE DATEN / DATOS TÉCNICOS

indication, basée sur les directives et les règlements de l'Union eu-

ropéenne, attribue une classe de mérite (de G à A ++) et permet aux

clients de faire des choix éclairés en fonction des consommations et

de l'efficacité.

Ab dem 1. Januar 2018 tritt die Energiekennzeichnung auch für alle

Wärmeerzeuger für Biomasseheizungen mit oder ohne Warmwas-

sererzeugung in Kraft. Diese auf Richtlinien und Verordnungen der

Europäischen Union basierende Indikation weist eine Leistungsklasse

(von G bis A ++) hin und ermöglicht dem Kunden eine fundierte Ent-

scheidungen auf der Basis des Kraftstoffverbrauchs und der Effizienz.

A partir del 1 Enero 2018 está en vigor el etiquetado energético tam-

bién para todos los calentadores de espacio para la calefacción por

biomasa con o sin producción de agua caliente sanitaria. Esta indi-

cación, basada en directivas y reglamentaciones de la Unión Europea,

asigna un valor de la escala de clasificación (de G hasta A++) y permi-

te que los clientes elijan siendo informados sobre gastos y eficiencia.

A

++

A

+

A

+

A

B

C

D

E

F

G

LxHxP

Potenza termica nominale utile (kW) / Nominal thermal power (kW) /

Puissance nominale utile (kW) / Nennwärmeleistung (kW) /

Potencia nominal útil (kW)

Potenza resa al liquido (kW) / Power given back to water (kW) /

Puissance rendue a l’eau (kW) / Wässerwarmeleistung (kW) /

Potencia suminstrada al liquido (kW)

m

3

riscaldabili (30 kcal/h x m

3

) / Heatable m

3

(30 kcal/h x m

3

) /

m

3

que l’on peut chauffer (30 kcal/h x m

3

) / Heizungsvermögen m

3

(30 kcal/h x m

3

) / m

3

calentables (30 kcal/h x m

3

)

Dimensioni LxHxP (mm) / Dimensions WxHxD (mm) /

Dimensions LxHxP (mm) / Maße BxHxT(mm) / Dimensiónes LxAlxAn (mm)

Peso netto (kg) / Net weight (kg) /

Poids net (kg) / Netto Gewicht (kg) / Peso Neto (kg)

Capacità totale serbatoio (kg-l) / Feed box total capacity (kg-l) /

Capacité totale réservoir (kg-l) / Tank-Gesamtkapazität (kg-l) /

Capacidad total depósito (kg-l)

Assorbimento elettrico (W) / Electric consumption (W) /

Absorption électrique (W) / Stromaufnahme (W) /

Consumo eléctrico (W)

Rendimento (%) / Efficiency (%) /

Rendement (%) / Wirkungsgrad (%) / Rendimiento (%)

Consumo orario (kg/h) / Hourly consumption (kg/h) /

Consommation (kg/h) / Stundenverbrauch (kg/h) / Gasto horario (kg/h)

Diametro tubo scarico fumi (mm) S=Superiore, P=Posteriore /

Smoke outlet diameter (mm) S=Top , P=Rear /

Diamètre sortie de fumées (mm) S=Au-dessus, P=À l'arriere /

Rauchrohrdurchmesser (mm) S=Oberer Rauchanschluss, P=Hinterer Rauchanschluss /

Dimensiones salida humos (mm) S=Superior , P=Posterior /

Contenuto fluido scambiatore (l) / Fluid contents of the exchanger (l) /

Liquide contenu dans l’echangeur (l) / Gehalt Fluessigkeit im Ausstauscher (l)

/ Contenido fluido intercambiador (l)

Pressione d’esercizio (bar) / Working pressure (bar) /

���

Puissance d’exercise (bar) / Arbeitsdruck (bar) / Presión de trabajo (bar)

Regolamento Italiano per il rilascio del certificato ambientale per i generatori di calore alimentati a

biomasse combustibili solide (classificazione da 1 a 5 stelle)

Aria Pulita, la certificazione volontaria italiana per la qualità dei sistemi di riscaldamento a biomasse

legnose (classificazione da 1 a 5 stelle con i medesimi parametri del DM186/2017).

COLORI / COLOURS / COULEURS / FARBEN / COLORES

Ametista

Amethyst

Améthyste

Amethyst

Amatista

Avorio

Ivory

Ivoire

Elfenbein

Blanco

Bianco

White

Blanc

Weiss

Blanco

Bordeaux

Burgundy

Bordeaux

Bordeaux

Burdeos

Fumè

Fumè

Fumè

Fumè

Negro ahumado

Grigio Luce

Grigio Luce

Grigio Luce

Grigio Luce

Grigio Luce

Madreperla

Mother of pearl

Nacre

Perlmutter

Nacar

Nero

black

Noir

Schwarz

Negro

Pergamena

Parchment

Parchemin

Pergament Beige

Pergamino

Pietra Naturale

Natural stone

Pierre naturelle

Naturstein

Piedra natural

Tortora

Tortora

Tortora

Tortora

Tortora

Tortora Lucido

Bright tortora

Tortora brillant

Glänzendes Tortora

Tortora brillante

CONTO TERMICO

Per maggiori informazioni

consultare il nostro sito:

www.lanordica-extraflame.com

Con il DM 28/12/12, meglio conosciuto come “Conto Termico”, si assegna

un incentivo specifico in caso di sostituzione di vecchi apparecchi con nuovi

prodotti con determinate caratteristiche.
