VRF - Sistemi a Flusso Refrigerante Variabile - Flow Systems réfrigérant variable - Variable Refrigerant Flow

TPV MINI VRF MULTI FULL DC INVERTER - R410a

DI PICCOLA POTENZA

DE PETITE PUISSANCE

OF SMALL POWER

CONTO

TERMICO

O

O

EER &COP

Unità Multi split Full DC Inverter a bassa capacità- R410a

Mod.

Power

Type

Cooling

Heating

Refrigerant Sound

pres-

sure

Sound

power

Dimension

Wei-

ght

Connection

Max

connection

indoor units

quantity

Capacity Power input

EER

Capacity Power input

COP

Type

Vol.

Net Gas Liquid

V/Ph/Hz kW/Btu kW/A kW/Btu kW/A Kg

dB(A) dB(A)

mm Kg mm

TPV-V

080W/R1

220-240/1/50 8/27300

2,15/5,70 3,72

9/30700

2,28/6,04 3,95

R

4

1

0

a

3,00

45~56 52~63

1054

x 994

x 399

80

Ø15,9

Ø9,53

4

TPV-V

100W/R1

220-240/1/50 10/34000

2,68/7,10 3,70

11,5/39000

2,90/7,69 3,93 3,00

45~56 52~63 80 5

TPV-V

125W/R1

220-240/1/50 12,5/42000

3,38/8,96 3,69 14/47000

3,65/9,68 3,83 3,10

45~58 52~65

900

x 1328

x 400

89 6

TPV-V

125W/ZR1

380-415/3/50 12,5/42000

3,38/5,24 3,69 14/47000

3,66/5,67 3,83 3,10

45~58 52~65 93 6

TPV-V

140W/R1

220-240/1/50 14/47000

3,96/10,50 3,52 16/54000

4,30/11,40 3,72 3,45

45~58 52~65 89 7

TPV-V

140W/ZR1

380-415/3/50 14/47000

3,98/6,17 3,52

16/54000

4,30/6,67

3,72

3,45

45~58

52~65

93

7

TPV-V

160W/R1

220-240/1/50 16/54000

4,57/12,11 3,50 18/61000

5,13/13,60 3,61 4,20

45~58 52~65 96 8

TPV-V

160W/ZR1

380-415/3/50 16/54000

4,58/7,10 3,50 18/61000

5,13/7,95 3,61 4,20

45~58 52~65 100 8

TPV-V

180W/ZR1

380-415/3/50 18/61000

5,19/8,05 3,47 20/63000

5,62/8,71

3,56

4,20

45~58

52~65

100

Ø19,1

9

TPV-VH

224W/ZR1

380-415/3/50 22,4/76500

6,74/10,5 3,32 25/85300

5,85/9,90 4,27 6,10

45~58 52~65

1120

x 1549

x 400

145

Ø22,2

10

TPV-VH

260W/ZR1

380-415/3/50 26/887000

7,54/12,1 3,45 28,5/97300

6,77/11,10 4,21 6,10

46~60 55~66 145 12

TPV-VH

280W/ZR1

380-415/3/50 28/95500

8,32/13,6 3,37 30,5/104000

7,93/12,9 3,85 8,00

47~60 56~66 176

Ø25,4

Ø12,7

15

TPV-VH

335W/ZR1

380-415/3/50 33,5/114200

9,45/14,9 3,54 37,5/127900

9,00/14,20 4,17 8,00

48~62 57~68 176 18

Note:

1. Condizione di raffrescamento: temperatura interna 27°C DB

(80.6°F.), 19°C WB (60°F), temperatura esterna 35°C DB (95°F),

lungh. tubo: 5m, lungh. max. di dislivello: 0m

2. Condizione di riscaldamento: temperatura interna 20°C DB

(68°F.), 15°C WB (44.6°F), temperatura esterna 7°C DB (42.8°F),

lungh. tubo: 5m, lungh. max. di dislivello: 0m

3. Livello sonoro: valore di conversione camera anecoica, misura-

to in un punto a 1 m davanti all’unità ad un’altezza di 1,2 m. Du-

rante il funzionamento effettivo, questi valori sono nella normalità

leggermente più alti a causa delle condizioni ambientali.

4. I dati sopra riportati possono essere modificati senza preavviso

per futuri miglioramenti in termini di qualità e prestazioni.

Notes:

1. Conditions de refroidissement: température interne DB 27 °

C (19 ° C), température extérieure DB 35 ° C (95 ° F), longueur.

tube: 5m, longueur max. différence de hauteur: 0 m

2. Conditions de chauffage: température interne 20 ° C DB (68 °

F), 15 ° C WB (44,6 ° F), température extérieure 7 ° C DB (42,8 °

F), longueur. tube: 5m, longueur max. différence de hauteur: 0m

3. Niveau sonore: valeur de conversion de la chambre

anéchoïque, mesurée en un point situé à 1 m en avant de l’unité

à une hauteur de 1,2 m. En fonctionnement réel, ces valeurs

sont légèrement supérieures à la normale en raison des condi-

tions environnementales.

4. Les données ci-dessus peuvent être modifiées sans préavis

pour de futures améliorations de la qualité et des performances.

Note:

1. Cooling condition: internal temperature 27 ° C DB (80.6 ° F.),

19°CWB(60°F),outdoortemperature35°CDB(95°F),

length. tube: 5m, length max. difference in height: 0m

2. Heating condition: internal temperature 20 ° C DB (68 ° F.),

15 ° C WB (44.6 ° F), outdoor temperature 7 ° C DB (42.8 ° F),

length. tube: 5m, length max. difference in height: 0m

3. Sound level: anechoic chamber conversion value, measured

atapointat1minfrontoftheunitataheightof1.2m.During

actual operation, these values are slightly higher in normal due to

environmental conditions.

4. The above data may be changed without notice for future

improvements in quality and performance.
