Sistema OLIflex D.P. Air PPs-

inox

Per rispondere alle esigenze del mercato e ampliare la

gamma di prodotti certificati, garantendo assoluta qualità

e convenienza, abbiamo creato “OLI

flex D.P. Air PPs-inox”.

La sua caratteristica principale consiste nello sfruttare

le proprietà fisiche dell’aria, non in movimento, come

coibentante naturale ed ecologico. Con il passaggio dei

fumi si riscalda il condotto interno plastico il quale, essendo

a contatto con l’aria nell’intercapedine, cede parte del

calore creando una coibentazione di ottima qualità.

Caratteristiche del prodotto



Prodotto certificato CE secondo lo standard UNI

EN 14471.



OLIflex D.P. Air PPs-inox è un sistema a doppia parete,

con intercapedine ad aria, adatto allo scarico dei prodotti

della combustione da caldaie a condensazione. L’uso

e collocazione di questo sistema è prevalentemente

esterno all’edificio.



Realizzato nei diametri: Ø 80/100 - Ø 100/120 mm.



Questo sistema composto da elementi modulari a

sezione circolare è adatto al funzionamento in pressione

positiva (5000 Pa con guarnizione) a umido (W) ed a una

temperatura massima di 120°C.



Compongono il sistema tutti gli elementi necessari alla

realizzazione di una canna fumaria, e sono: raccordo

TEE 93°- Supporto a muro - Scarico condensa - Curva

45°- Elemento d’ispezione - Terminali ed accessori vari.



Le principali normative di riferimento: UNI EN 1443 -

UNI EN 14471 - UNI EN 13384/1 - UNI 7129.

System OLIflex D.P. Air PPs-inox

To satisfy the market demands and increase the range

of certified products, ensuring outstanding quality and

convenience, OLI has developed “OLIflex D.P. Air PPs-inox”.

Its main feature consists in exploiting the physical

characteristics of the air, not in motion, as natural and

ecologic thermal insulation. By exploiting the smokes

passage, the internal conduct in plastic material gets warm

and, being in contact with the air (inside the interspace),

it passes part of the heat, creating this way a very good

thermal insulation.

Product features



CE certified product according to UNI EN 14471

standard

56

www.oli-world.com











OLIflex D.P. Air PPs-inox is a double wall system, with

air interspace, suitable for discharging condensation

boiler combustion products. Use and location of this

system is mainly outside the building.

Diameters available: Ø 80/100 and Ø 100/120 mm.

This system, composed of circular modular elements,

is suited to work in wet (W) positive pressure (5000 Pa

with seal) and with a maximum temperature of 120°C.

System composed by all the elements necessary to the

construction of a flue. Specifically: TEE 93° connector

- wall support - condensation discharge - 45° Curves -

Inspection Element - Terminals and accessories.

Main standard references: UNI EN 1443 - UNI EN 14471

- UNI EN 13384/1 - UNI 7129.
