Order no.
Gauge
Connection
Hose connection
Flow rate
Acoustic class
3.3375.7.004.136.1 / with accessories
3.3375.7.004.400.1 / without accessories
134 - 166 mm
1/2“
1/2“ (DN15)
9.9 l/min (3 bar)
IA
Specification
Accessories incl.
Mounting acc. incl.
Surface finish
thermostatic shower mixer
temperature handle with safety button 38°C
the mixer does not become hot
intrinsically safe against backflow
order no. 3.3375.7.004.136.1 – complete with
synthetic flexible hose 1500 mm and handshower
MyCity100
wall connections
chrome
20150612
1
3
4
-
1
6
6
Ø
6
7
.
5
6
2
1
2
6
3
1
0
