SOTTILE
Suspension / Direct / Indoor
Material
Metal
Finish
.03 Matt White
Davide Groppi / 2023
Davide Groppi / 2023
SOTTILE
.04 Matt Black
Note
Suspension luminaire. Matt white rose. AISI 304 stainless steel
.36 Brushed Black
Apparecchio illuminante a sospensione. Rosone bianco opaco. Cavo di
302
303
suspension cable. White cable for the matt white finish, black cable for
the other finishes. SOTTILE 1 DE and SOTTILE 2 DE: mono on/off and
dual emission version. SOTTILE 2 and SOTTILE 2 DE: version with power
cable only and without rose. Luminaire designed to be powered by our
ENDLESS conductive tape and dedicated voltage/current (Max 48V DC -
Max 150W - Max 4A). See page: ENDLESS.
SOTTILE 1
Ceiling driver version
21W
220-240V - 50/60Hz
2700K - 1692lm / 3000K - 1855lm
CRI >90
Driver integrated
DALI - PUSH - 1-10V - TRIAC
SOTTILE 1 DE
Ceiling driver version - Dual emission
41W
220-240V - 50/60Hz
2700K - Up 1692lm - Down 1692lm /
3000K - Up 1855lm - Down 1855lm
CRI >90
Driver integrated
DALI - PUSH - 1-10V - TRIAC
Matt White - 2700K - DALI - PUSH - 1-10V - TRIAC
Matt White - 3000K - DALI - PUSH - 1-10V - TRIAC
Matt Black - 2700K - DALI - PUSH - 1-10V - TRIAC
Matt Black - 3000K - DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 2700K - DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 3000K - DALI - PUSH - 1-10V - TRIAC
Brushed Black - 2700K - DALI - PUSH - 1-10V - TRIAC
Brushed Black - 3000K - DALI - PUSH - 1-10V - TRIAC
Matt White - 2700K - DALI - PUSH - 1-10V - TRIAC
Matt White - 3000K - DALI - PUSH - 1-10V - TRIAC
Matt Black - 2700K - DALI - PUSH - 1-10V - TRIAC
Matt Black - 3000K - DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 2700K - DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 3000K - DALI - PUSH - 1-10V - TRIAC
Brushed Black - 2700K - DALI - PUSH - 1-10V - TRIAC
Brushed Black - 3000K - DALI - PUSH - 1-10V - TRIAC
1A4230300.27.05
1A4230300.30.05
1A4230400.27.05
1A4230400.30.05
1A4232900.27.05
1A4232900.30.05
1A4233600.27.05
1A4233600.30.05
1A4640300.27.05
1A4640300.30.05
1A4640400.27.05
1A4640400.30.05
1A4642900.27.05
1A4642900.30.05
1A4643600.27.05
1A4643600.30.05
Driver not included
Compulsory accessories / Accessori obbligatori
.29
sospensione in inox AISI 304. Cavo bianco per la finitura bianco opaco
e cavo nero per le altre finiture. SOTTILE 1 DE e SOTTILE 2 DE: versione
monoaccensione a doppia emissione. SOTTILE 2 e SOTTILE 2 DE: versione
con solo il cavo di alimentazione e senza rosone. Alimentabile anche con
il tape conduttivo ENDLESS e tensione/corrente dedicata (Max 48V DC -
Max 150W - Max 4A). Vedi pagina ENDLESS.
SOTTILE 2
Remote driver version
19W
24V DC
2700K - 1692lm / 3000K - 1855lm
CRI >90
Driver not included
SOTTILE 2 DE
Remote driver version - Dual emission
2x19W
24V DC
2700K - Up 1692lm - Down 1692lm /
3000K - Up 1855lm - Down 1855lm
CRI >90
Matt White - 2700K
Matt White - 3000K
Matt Black - 2700K
Matt Black - 3000K
Brushed Bronze - 2700K
Brushed Bronze - 3000K
Brushed Black - 2700K
Brushed Black - 3000K
Matt White - 2700K
Matt White - 3000K
Matt Black - 2700K
Matt Black - 3000K
Brushed Bronze - 2700K
Brushed Bronze - 3000K
Brushed Black - 2700K
Brushed Black - 3000K
1A4230300.27.20
1A4230300.30.20
1A4230400.27.20
1A4230400.30.20
1A4232900.27.20
1A4232900.30.20
1A4233600.27.20
1A4233600.30.20
1A4640300.27.20
1A4640300.30.20
1A4640400.27.20
1A4640400.30.20
1A4642900.27.20
1A4642900.30.20
1A4643600.27.20
1A4643600.30.20
1Z1120490
1Z2170010
Brushed Bronze
Drivers / Alimentatori
Driver / Alimentatore
100-240V
Controller
24V/50W/IP20/ON/OFF
DALI - PUSH - 0/1-10V - TRIAC - IP20
SOTTILE 2 / SOTTILE 2 DE
SOTTILE 2 / SOTTILE 2 DE
Not included
Not included
5
0
5
0
0
0
5
0
5
0
0
0
7
