ASINTOTO

Ceiling / Indirect / Indoor

Davide Groppi / 2023

Davide Groppi / 2023

Optional accessories / Accessori opzionali

ASINTOTO

Material

Finish

Note

Metal - Methacrylate

.27 Gravity Black

Ceiling luminaire. Disc with Gravity Black finish. Magnetic weight available

for disc tilting. Black cable.

ASINTOTO

18W

Max 500mA DC

2700K - 1435lm / 3000K - 1481lm

CRI >90

Driver not included

Installation kits / Kit d'installazione

Apparecchio

Disponibile un peso magnetico per l’orientamento inclinato del disco. Cavo

nero.

Circular plasterboard panel 12,5 mm / Botola circolare per cartongesso 12,5 mm

Standard

Cut-out 400x400 mm

Minimum space for mounting 115 mm

Remote clamp for elettrical cable / Bloccacavo remoto per cavo elettrico

Standard

1A4520000.00.00

1X0110000.01.00

Not included

Not included

Not included

Not included

Not included

Not included

illuminante

da soffitto.

Disco

con finitura

Gravity

Black.

Suspension kits / Kit di sospensione

Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm

Gravity Black - 2700K

Gravity Black - 3000K

1A4072700.27.20

1A4072700.30.20

Matt White

Matt Black

For elettrical cables - 1 Piece

Plasterboard cut-out Ø 44 mm

Minimum space for mounting 70 mm

For elettrical cables - 1 Piece

Plasterboard cut-out Ø 44 mm

Minimum space for mounting 70 mm

1X0000300.04.00

1X0000400.04.00

1X0010300.04.00

1X0010400.04.00

1X0050300.01.00

1A4710400.00.00

Compulsory accessories / Accessori obbligatori

Ceiling suspension kit / Kit di sospensione da soffitto

Matt White

For elettrical cables - 1 Piece

Matt Black

For elettrical cables - 1 Piece

Wall adapter plate / Piastra di adattamento da parete

Matt White

For mounting on brick masonry walls

Magnetic weight / Peso magnetico

Drivers / Alimentatori

Driver / Alimentatore

220-240V(100-127V)

Driver / Alimentatore

220-240V(100-127V)

Driver / Alimentatore

220-240V

500mA/20W(15W)/IP20/DALI

500mA/20W(15W)/IP20/PUSH - 1-10V

500mA/20W/IP20/TRIAC/IGBT

1Z0241180.500

1Z0240870.500

1Z0240850.500

Not included

Not included

Not included

Other accessories / Altri accessori

Matt Black

For sloped installation

420

421
