DOT R

Recessed / Direct / Indoor

Material

Finish

Note

Omar Carraglia - Davide Groppi / 2015

Omar Carraglia - Davide Groppi / 2015

Compulsory accessories / Accessori obbligatori

DOT R

Metal

.03 Matt White

.49 Matt Black/Polished Gold

Foro del cartongesso: 40x40 mm. Spazio minimo per incasso: 60 mm.

Drivers / Alimentatori

.04 Matt Black

Recessed luminaire. Adjustable in all directions. Plasterboard hole: Apparecchio illuminante da incasso. Orientabile in tutte le direzioni.

Driver / Alimentatore

220-240V(100-127V)

Driver / Alimentatore

220-240V(100-127V)

Driver / Alimentatore

220-240V

Lens / Lente

Beam - 14°

Beam - 24°

Beam - 36°

Beam - 50°

350mA/17W(15W)/IP20/DALI

350mA/18W(15W)/IP20/PUSH - 1-10V

350mA/17W/IP20/TRIAC/IGBT

2700K - CRI >97 - 983lm

3000K - CRI >97 - 1038lm

2700K - CRI >97 - 943lm

3000K - CRI >97 - 996lm

2700K - CRI >97 - 955lm

3000K - CRI >97 - 1005lm

2700K - CRI >97 - 965lm

3000K - CRI >97 - 1016lm

DOT R

DOT R

DOT R

DOT R

DOT R

DOT R

DOT R

1Z0241180.350

1Z0240870.350

1Z0240850.350

1A3090000.00.00

1A3100000.00.00

1A3110000.00.00

1A3120000.00.00

Not included

Not included

Not included

Not included

40x40 mm. Minimum space for recessed installation: 60 mm.

DOTR

13W

Max 350mA DC

2700K / 3000K

CRI >97

Driver not included

DOT R 51

Max 10W - GU10

100-240V - 50/60Hz

ON/OFF

Bulb not included

Matt White - 2700K

Matt White - 3000K

Matt Black - 2700K

Matt Black - 3000K

Matt Black/Polished Gold - 2700K

Matt Black/Polished Gold - 3000K

1A4770300.27.20

1A4770300.30.20

1A4770400.27.20

1A4770400.30.20

1A4774900.27.20

1A4774900.30.20

Other accessories / Altri accessori

Matt White - ON/OFF

Matt Black - ON/OFF

Matt Black/Polished Gold - ON/OFF

1A3700300.00.00

1A3700400.00.00

1A3704900.00.00

472

473
