BUBKA

Floor / Direct / Outdoor

Daniele Sprega / 2014

Daniele Sprega / 2014

Compulsory accessories / Accessori obbligatori

BUBKA

Material

Finish

Note

AISI 316L Stainless Steel - Metal

.00 Standard

Outdoor floor luminaire. Adjustable along the vertical axis. AISI 316L Apparecchio illuminante da esterno da terra. Orientabile lungo l’asse

Drivers / Alimentatori

Driver / Alimentatore

220-240V(100-127V)

700mA/30W(15W)/IP68/ON/OFF

1Z0241110

1A1660000.00.00

1A3620000.00.00

1A3610400.30.20

1A3610400.27.20

Not included

Included

Not included

Not included

stainless steel stem. Black cable (7 m).

BUBKA

8,4W

Max 700mA DC

2700K - 639lm / 3000K - 639lm

CRI >90

Driver not included

verticale. Stelo in inox AISI 316L. Cavo nero (7 m).

Optional accessories / Accessori opzionali

Installation kits / Kit d'installazione

Standard - 2700K

Standard - 3000K

1A3600000.27.20

1A3600000.30.20

Driver connector IP68 / Connettore driver IP68

1 Piece

Anchoring bolt / Tirafondo

Cut-out Ø 250 mm

Minimum space for mounting 350 mm

Additional LED head / Testa LED supplementare

Lighting modules / Corpi illuminanti

Matt Black

Max 700mA DC - 8,4W

3000K - 639lm - CRI >90

Max 700mA DC - 8,4W

2700K - 639lm - CRI >90

702

703
