HANSA | LIVING
HANSALOFT
57572183
Chrome
EAN 4057304014765
Valid From: 01-04-2020
Issue 01/2020
31
HANSALOFT
Washbasin faucets
Trim Kit/Single-lever
Wall mounted for concealed unit,
DN15
Flow-rate at 3 bar (with flow controller): 6 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
•
• Hot/Cold symbols
•
Backflow prevention (EN1717): AA
•
• Consisting of: Square rosette | Sleeve | Operating
lever
Required sales items
HANSAMATRIX Installation technology
HANSAMATRIX
Installation technology
Concealed unit
Wall mounted, DN15
• Body made of DZR brass
• Multifix fastening system
• Rotating installation option
• protected against back-flow in domestic
use (according to DIN EN 1717)
Installation depth: 65 - 90 mm
Flow-rate at 3 bar: 21.6 l/min
Hot water supply: max. +90°C
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• G1/2
€ 352,00
Accessories: Assembling plate, 4405 0000; Assembling plate, 4405 0100
HANSALOFT
Washbasin faucets
Trim Kit/Single-lever
Wall mounted for concealed unit,
DN15
Flow-rate at 3 bar (with flow controller): 6 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
• Hot/Cold symbols
• Consisting of: Soft edge rosette | Sleeve
• Projection: 193 mm
Accessories: Angle piece, 59 913 086
Required sales items
HANSAVARIO Installation technology
57772103
Chrome
EAN 4015474263710
€ 352,00
Projection: 197 mm
Fixed spout
Aerator type: HONEYCOMB® - improved lime
protection | CACHÉ® - hidden aerator without
housing | Adjustable flow angle
H
A
N
S
A
L
O
F
T
4400 0100
44000100
EAN 4057304006661
€ 191,00
• Ø 40 mm ceramic cartridge for flow and tempera-
ture control
• Consisting of: Gasket sleeve for dry mortar-
less construction | Mounting box and cover sleeve
• Fixed spout
• Aerator type: HONEYCOMB® - improved lime
protection | CACHÉ® - hidden aerator without
housing | Adjustable flow angle
5786 0100
