Specifiche tecniche

Modello

Portata aria unità trattamento aria

(m

3

/h)

Volume batteria

ad espansione diretta

(dm

3

)

Capacità raffrescamento

(kW)

Capacità riscaldamento

(kW)

Unità esterne DI

[SM]

Unità esterne SDI

[SP]

Taglia

Min.

Nominale

Max

Min.

Max

Min.

Nominale

Max

Min.

Nominale

Max

(RAV-***-E)

(RAV-***-E)

720

900

1080

0,8

1,1

4,1

5,3

5,6

4,6

5,6

6,3 SM

7,4 SP

GM561ATP

GP561ATP

3 HP

1060

1320

1580

1,0

1,4

5,4

7,1

7,4 SM

8,0 SP

7,5

8,0

9,0 SM

10,6 SP

GM801ATP

GP801AT

1280

1600

1920

1,5

2,1

7,2

10,0

12,5 SM

12,0 SP

8,1

11,2

12,5 SM

13,0 SP

GM1101AT(8)P

GP1101AT

SP1104AT8

5 HP

1680

2100

2520

1,7

2,7

10,1

12,5

13,2 SM

14,0 SP

11,3

14,0

16,0 SM

16,5 SP

GM1401AT(8)P

GP1401AT

SP1404AT8

1850

2800

3740

1,7

3,2

12,6

14,0

16,0

14,1

16,0

19,0

SM1603AT

SP1604AT8

8 HP

2880

3600

4320

3,0

4,2

14,1

20,0

22,4

16,1

22,4

25,0

SM2246AT8

-

3360

4200

5040

3,0

5,4

20,1

23,0

27,0

22,5

27,0

31,5

SM2806AT8

-

2 HP

4 HP

6 HP

10 HP

NOTE:

Le potenzialità in raffrescamento e in riscaldamento sono teoriche: la conformazione dello scambiatore di calore dell’ UTA, scelta dal cliente, può avere un impatto sulle prestazioni del sistema.

Range temperature di funzionamento:

- in Riscaldamento alla portata d’aria nominale - temperatura interna 27°C BS/19°C BU e temperatura esterna 35°C BS

- in Condizionamento alla portata d’aria nominale - temperatura interna 20°C BS e temperatura esterna 7°C BS/6°C BU

Unità trattamento aria con batteria ad espansione diretta

RBC-AMS55E-EN

Unità SDI/DI

RAV-DXC010
