VENTILATORI CENTRIFUGHI PALE ROVESCE

Backward curved blade centrifugal fans

Versioni / Versions

Versioni antideflagranti

a norme ATEX

Explosion-proof versions

according to ATEX directive

Versioni alta temperatura

per estrazioni fumi di incendio

High Temperature versions

for smoke extraction in case of fire

Versioni per alta temperatura

con funzionamento in continuo

High Temperature versions

for continuous running

Ventilatori centrifughi pale rovesce

Backward curved blade centrifugal fans

PR-Q AT

pag.146

Ventilatori centrifughi pale rovesce per

aria pulita o leggermente polverosa

Backward curved blade centrifugal fans for clean and slightly dusty air

Ventilatori centrifughi pale rovesce per

aria pulita e leggermente polverosa

Backward curved blade centrifugal fans for clean or slightly dusty air

Ventilatori centrifughi pale rovesce per aria polverosa

Backward curved blade centrifugal fans for dusty air

Ventilatori centrifughi pale rovesce per aria polverosa

Backward curved blade centrifugal fans for dusty air

Ventilatori centrifughi pale rovesce

Backward curved blade centrifugal fans

Accessori / Accessories - PR-Q

pag.150

PR-L

pag.152

PS-L

pag.170

PV-L

pag.186

PQ-L

pag.190

Abbinamento a regolatori di velocità e inverter

pag. 302

Speed regulators-inverter pairing

Collegamenti elettrici / Wiring diagrams

pag. 320

Ventilatori centrifughi pale rovesce serie

PS-L / PQ-L / PR-L / PV-L

Backward curved blade centrifugal fans

Series PS-L / PQ-L / PR-L / PV-L

90

Le serie PR-L, PS-L, PV-L e PQ-L rientrano nel campo di applicazione

80

PQL

85

PSL

della Direttiva ErP 2009/125/CE e del Regolamento UE 327/2011

e sono conformi ai requisiti da essi definiti. I dati di prestazione

energetica saranno forniti a richiesta o in fase di consegna, in funzione

dell’effettivo punto di lavoro della macchina ordinata. A titolo indicativo,

riportiamo nel grafico seguente l’esito dei test prestazionali effettuati

sulle serie interessate a dimostrazione che l’efficienza complessiva di

ogni macchina è maggiore dell’efficienza energetica obiettivo.

PRL

75

PVL

70

65

60

55

50

45

The series PR-L, PS-L, PV-L e PQ-L are affected by the Erp Directive

2009/125/CE and comply with the efficiency requirements established

by UE Regulation 327/2011. The efficiency performance data are

available upon request or at delivery according to the effective working

point of the oredered model.. We report in the following graph the

results of the performance tests made on the series as an demostration

that the total efficiency of each single fan is superior to the efficiency

40

target established by the regulation.

0

50

100

150

200

250

300

Potenza installata [kW]
