ACCESSORI Accessories

DA-T

FLANGIA PREMENTE - OUTLET FLANGE

La flangia viene montata sulla bocca premente del ventilatore e facilita la con-

nessione con la canalizzazione.

The flange is fitted on fan outlet and allows an easier connection to the duct.

Cod.

TIPO

TYPE

A B

C

D E F

5BO0102

7/7

273 262

225

215 126,5 121

5BO0107

9/7

273 300

225

253 126,5 140

5BO0110

9/9

340 300

292

253 160 140

5BO0113

10/8 317 340

260 282 146,5 158

5BO0116

10/10 383 340

326 282 179,5 158

5BO0119

12/9 365 395

304 333 170,5 187

5BO0122

12/12 450 395

388 333 213 187

5BO0123

15/11 426 460

365 395 201 218

5BO0125

15/15 526 460

465 395 251 218

5BO0126

18/13 498 544

428 474 234 257

5BO0129

18/18 618 544

548 474 294 257

=

C

=

Ø5

=

E

E

=

15

Dimensioni in mm / Dimensions in mm

A

STAFFE DI FISSAGGIO - SUPPORT FEET

Consentono l’ancoraggio del ventilatore.

Possibilità di orientamento della bocca premente di 90° in 90°.

Used for fan fitting. Possibility of orientation of the fan outlet by steps of 90°.

=

SUPPORTO MOTORE - MOTOR SUPPORT

Si dispone trasversalmente alla chiocciola permettendo il montaggio del mo-

tore in esecuzione 14/D.

It is arranged across the casing allowing the assembly of the motor in exe-

cution 14/D.

Dimensioni in mm / Dimensions in mm

Cod.

TIPO

TYPE

A B

C

D

5PI2981

7

254 47

26

227

5PI2985

9

325 102

26

297

5PI2989

10

363 102

26

339

5PI2993

12 434 144

26 407

5PI2997

15 521 164

26 494

5PI2998

18 635 186

26 608

C

=

D

sez.

1

.8

A

Cod.

TIPO

TYPE

A

5SU3002

7/7 232

5SU3003 9/7 232

5SU3004

9/9 300

5SU3005 10/8 266

5SU3006 10/10 333

5SU3007 12/9 313

5SU3008 12/12 396

5SU3009 15/11 373

5SU3010 15/15 473

5SU3011 18/13 436

18/18 556

A

49

Dimensioni in mm / Dimensions in mm
