design techniques

The tiles in all of the Ceramica Vogue collections were designed to be laid in

combination: the calibers of the different sizes are therefore compatible. The

possibility to combine colours, finishes and sizes in a multitude of different ways is

an excellent solution for designers, allowing them to satisfy all kinds of technical

requirements without underestimating the demands for decoration and style.

The measurements provided indicate the average production size referring to the

central caliber. The size tolerances within the same caliber are laid down in the

398,8 mm

198,4 mm

16"

8"

standard UNI EN 14411 and are usually compensated by laying the material as

per our instructions. It is possible that lower or higher calibers than the central

one are supplied: thus the average manufacturing sizes may vary. In this regard,

it is recommended to indicate in the order the sizes you intend to use for the

composition, in order to ensure that they are supplied with compatible calibers.

Modularity and laying

48,1 mm

198,4 mm

2"

8"

98,2 mm

48,1 mm 48,1 mm

4"

2"

2"

40x40

16"x16"

20x40

8"x16"

5x40

2"x16"

20x20

8"x8"

10x10

4"x4"

5x5

2"x2"

5x5

2"x2"

5x5

2"x2"

5x5

2"x2"

10x10

4"x4"

10x10

4"x4"

5x20

2"x8"

10x10

4"x4"

10x20

4"x8"

10x10

4"x4"

10x10

4"x4"

10x20

4"x8"

To obtain a correct laying result the material should be laid with joints of no less than

0,85 cm

0,7 cm

5x40 - 20x40 - 40x40

5x5 - 10x10 - 10x20 - 20x20 - Bisello

(UNI 11493:2013).
