Info and menu parameters

ES 5941Z

BAS09

TIME OF DAY

Time of day

The time of day is automatically

adjusted to daylight saving time

and to standard time.

00:00

-

0

02:72

BAS10

DATE

Date

yyyy

dd:mm

-

0

02:070

BAS15

MIN TEMP

HEAT

SOURCE

Primary/tank

minimum

temperature

If the temperature in the tank is

< setting, the station is switched

off and an "11” status message is

generated.

0...90

°C

25

05:058

BAS16

DAYLIGHT

SAVING TIME

Daylight

saving time

Suppression of the automatic

changeover from daylight saving

time to standard time:

n off: automatic changeover

from daylight saving time to

standard time

n on: automatic changeover

from daylight saving time to

standard time is suppressed

on/off

-

25

04:003

PAR

SET VALUE

ZIR

CIRCULATION

Adjuster is visible if circulation mode ZIR00 (05:006) is not set to 0.

ZIR00

CIRCULATION

MODE

Circulation pump function (see above for basic

parameters)

0...3

-

0

05:006

ZIR01

TEMP.REDUCE

TSET CIRC.

Setpoint

reduction for

circulation

return

Setpoint reduction for circulation

return, results in the circulation

setpoint temperature that is to be

reached at sensor TBZ. TBZset =

TWWset - TWWset_return

0...90

°C

0

05:054

ZIR04

TBZ SENSOR

TYPE

TBZ circula-

tion sensor

selection,

sensor type

n 0: NTC 5K

n 1: PT 1000

0...1

-

25

05:088

ZIR05

TOLERANCE

CALI. CIRC

Circulation

flow rate tol-

erance

Circulation flow rate tolerance.

Maximum permissible deviation

below the flow rate measured

values in relation to calibration.

0...100

%

25

36:011

ZIR06

CIRC. CALI-

BRATION

Circulation

flow rate cali-

bration

n 0: Off = no calibration.

n 1: Manual = calibrate 1x.

No automatic reset to 0. Set

to 0 and then to 1 in order to

calibrate again.

n 2: Auto = Calibrate each

Monday at 2 am.

0...2

-

25

36:010

03/2024 Item no. 215790 EA no. 1321

29
