ATHENA-C

POMPA DI CALORE

ARIA-ACQUA MONOBLOCCO

INTERNA

INTERNAL AIR-TO-WATER

MONOBLOC HEAT PUMP

Alimentazione - Power Supply

FULL DC

INVERTER

CALDO

E FREDDO

TEMP. ARIA

MINIMA -25°C

WI-FI

TEMP. ACS

MASSIMA 55°C

GLICOL

FREE

GLICOL

FREE

MAX

R32

TEMP. AT

CONTO

REFRIGERANTE

V-Hz-Ph

230-50-1

MASSIMA 60°C

TERMICO 2.0

R32

Pompa di calore aria-acqua monoblocco interna Internal air-to-water monobloc heat pump

Codice Set - Set Code

A-0532-C200

A-0732-C200

A-0932-C200

Modulo PDC - HP Unit

A-0532-C

A-0732-C

A-0932-C

Modulo ACS - DHW Unit

A-0532-C DHW

A-0732-C DHW

A-0932-C DHW

Raffreddamento

Cooling

capacity

A35/W7

Potenza - Capacity

Nom. (min-max)

kW

3.21 (1.65~4.28)

4.35 (2.75~6.01)

6.12 (3.58~7.45)

P assorb. - Power

Nom. (min-max)

kW

1.26 (0.68~2.01)

1.71 (1.07~2.38)

2.30 (1.37~3.21)

EER

Nominale

W/W

2.55 (2.41~3.05)

2.54 (2.38~3.06)

2.66 (2.45~3.08)

Raffreddamento

Cooling

capacity

A35/W18

Potenza - Capacity

Nom. (min-max)

kW

4.81 (1.85~5.56)

6.79 (2.93~7.22)

8.79(3.71~9.35)

P assorb. - Power

Nom. (min-max)

kW

1.15 (0.62~2.03)

1.65 (1.05~2.12)

2.14 (1.32~3.15)

EER

Nominale

W/W

4.18 (2.49~5.02)

4.12 (2.48~5.11)

4.11 (2.52~5.12)

Riscaldamento

Heating capacity

A7/W35

Potenza - capacity

Nom. (min-max)

kW

5.06 (2.37~6.82)

6.16 (3.26~7.43)

8.58 (4.50~10.26)

P assorb. - Power

Nom. (min-max)

kW

1.27 (0.52~1.68)

1.58 (0.82~1.91)

2.11 (1.07~2.50)

COP

Nominale

W/W

3.98 (3.30~5.23)

3.90 (3.30~5.21)

4.07 (3.30~5.23)

Riscaldamento

Heating

capacity

A7/W55

Potenza - capacity

Nom. (min-max)

kW

4,12 (2,64~4,34)

5,02 (3,21~5,28)

6,99 (4,47~7,36)

P assorb. - Power

Nom. (min-max)

kW

1,45 (1,03~1,60)

1,80 (1,27~1,99)

2,39 (1,70~2,66)

COP

Nominale

W/W

2,85 (2,57~ 2.71)

2,79 (2,52~2,65)

2,92 (2,63~2,77)

Riscaldamento

Heating capacity

A2/W35

Potenza - capacity

Nom. (min-max)

kW

4.52 (2.92~6.42)

5.76 (2.92~7.32)

7.89 (3.74~9.22)

P assorb. - Power

Nom. (min-max)

kW

1.19 (0.52~1.66)

1.52 (0.82~1.86)

2.05 (1.02~2.45)

COP

Nominale

W/W

3.80 (2.30~4.60)

3.79 (2.30~4.21)

3.85 (2.40~4.20)

Riscaldamento

Heating capacity

A-7/W35

Potenza - capacity

Nom. (min-max)

kW

3.72 (2.22~4.60)

5.03 (2.52~5.86)

6.33 (3.28~7.71)

P assorb. - Power

Nom. (min-max)

kW

1.15(0.48~1.62)

1.57 (0.79~1.78)

1.95 (0.99~2.48)

COP

Nominale

W/W

3.23 (2.56~3.84)

3.20 (2.56~3.64)

3.25 (2.64~3.96)

Riscaldamento

Heating capacity

A-7/W55

Potenza - capacity

Nom. (min-max)

kW

3,03 (1,94~3,19)

4,10 (2,62~4,31)

5,16 (3,30~5,43)

P assorb. - Power

Nom. (min-max)

kW

1,31 (0,93~1,45)

1,79 (1,27~1,98)

2,21 (1,57~2,46)

COP

Nominale

W/W

2,31 (2,09~2,20)

2,29 (2,07~2,18)

2,33 (2,10~2,21)

Riscaldamento

Heating capacity

A-15/W35

Potenza - capacity

Nom. (min-max)

kW

3,36 (2,15~3,54)

4,21 (2,70~4,43)

5,30 (3,39~5,57)

P assorb. - Power

Nom. (min-max)

kW

1,24 (0,88~1,38)

1,49 (1,06~1,65)

1,84 (1,31~2,04)

COP

Nominale

W/W

2,70 (2,44~2,57)

2,83 (2,55~2,69)

2,87 (2,59~2,73)

Riscaldamento

Heating capacity

A-15/W55

Potenza - capacity

Nom. (min-max)

kW

2,45 (1,57~2,58)

3,43 (2,19~3,61)

4,32 (2,76~4,54)

P assorb. - Power

Nom. (min-max)

kW

1,34 (0,95~1,48)

1,70 (1,20~1,87)

2,10 (1,49~2,33)

COP

Nominale

W/W

1,83 (1,66~1,74)

2,02 (1,83~1,93)

2,06 (1,86~1,95)

Classe energetica - Energy class

Compressore - Compressor

Tipo di compressore - Type of compressor

Ventilatore - Fan

Refrigerante - Refrigerant

Tipo - Type

Carica - Charge

Regolazione - Regulation

Sbrinamento - Defrosting

Scambiatore di calore - Heat exchanger

-

A+++/A+++

-

1 x Mitsubishi

-

DC Inverter

-

1 AC

-

R32

gr

650

700

-

EEV

1500

-

Auto-defrosting

-

Scambiatore a piastre - Brazed plate heat exchanger (SWEP)

Circolatore - Circulation pump

-

Tubazioni acqua - Water connections

Inch

Flussostato - Water

flow switch

-

Portata d’acqua nominale - Nominal water rate

m

3

/h

Pressione sonora - Sound level

dB(A)

1,1

50

SHIMGE APM25-12-180

1”

SIKA

1,4

50

1,8

50

136

177.0% / 134.5%

130%

Temperatura minima acqua di raffreddamento

Minimum cooling water temperature

Temperatura massima AT - Maximum water temperature

Temperatura massima ACS - Maximum DHW temperature

Dimensioni modulo PDC - Dimensions (LxPxH)

Dimensioni modulo ACS - Dimensions (LxPxH)

Peso - Weight

Grado di protezione - Degree of protection

Limiti di funzionamento temperatura esterna

External operating temperature limits

°C

8

°C

°C

mm

mm

Kg

118

60

55

870 x 705,6 x 1178,5

870 x 705,6 x 1178,5

127

IPX4

-20~43

177.0% / 134.5%

130%

1,5

1,5

200

Ef

ficienza energetica stagionale

Seasonal energy ef

ficiency

ETAS 35°/55°

ACS - DHW 55°

-

°C

kW

kW

L

177.0% / 134.5%

130%

Resistenza elettrica modulo PDC - HP Unit electric heater

Resistenza elettrica modulo ACS - DHW Unit electric heater

Volume acqua sanitaria - DHW tank volume

Volume acqua tecnica - Buffer tank volume

L

10

mm

700x900

L

6

L

12

Dimensione griglia esterna - External grid size

Vaso di espansione impianto - Plant expansion tank

Vaso di espansione ACS - DHW expansion tank

CONDIZIONI DI CALCOLO:

TEST CONDITION:

1. A7/W35: temp. aria esterna 7°C DB/6°C WB, temp. acqua ingresso/uscita 30°C/35°C

2. A2/W35: temp. aria esterna 2°C DB/1°C WB, temp. acqua ingresso/uscita 30°C/35°C

3. A-7/W35: temp. aria esterna -7°C DB/-8°C WB, temp. acqua ingresso/uscita 30°C/35°C

4. A35/W7: temp. aria esterna 35°C , temp. acqua ingresso/uscita 12°C/7°C

1. A7/W35: outdoor air temp. 7°C DB/6°C WB, water inlet/outlet temp. 30°C/35°C

2. A2/W35: outdoor air temp. 2°C DB/1°C WB, water inlet/outlet temp. 30°C/35°C

3. A-7/W35: outdoor air temp. -7°C DB/-8°C WB, water inlet/outlet temp. 30°C/35°C

4. A35/W7: outdoor air temp. 35°C , water inlet/outlet temp. 12°C/7°C
