ME-AC-MBS-100V2

INTERFACCIA B.M.S. PER RETI MODBUS

®

ME-AC-MBS-100V2 – Interfaccia B.M.S.

per reti Modbus

®

Il protocollo Modbus è un protocollo di comunicazione utilizzato inizialmente

per le reti PLC . Mitsubishi Electric offre una interfaccia per la gestione di

max. 100 unit

à interne (ME-AC-MBS-100) per la gestione tramite B.M.S. del

sistema VRF CITY MULTI e HYDRONIC VRF.

L’interfaccia

è collegata al sistema di supervisione Modbus tramite al-

ternativamente un collegamento seriale RS232/RS485 o TCP/IP over

Ethernet e tramite Ethernet verso il sistema VRF CITY MULTI e SISTEMA

IDRONICO PACKAGED HVRF di Mitsubishi Electric.

Cavo Ethernet

AE-200

AE-200

Switch

Interfaccia

ME-AC-MBS-100

Bus M-Net

Bus M-Net

Sistema di

supervisione

Modbus®

Unit

à esterna

RS232/RS485 o Ethernet
