MAGIA

Luminaire UL certification pending. Available for CN market.

Apparecchio illuminante con certificazione UL in corso. Disponibile per mercato CN.

Michele Groppi / 2023

Michele Groppi / 2023

Compulsory accessories / Accessori obbligatori

Ceiling driver / Driver da sof

fitto

Matt White

Input 220-240V - 50/60Hz - Output 24V - 21W - IP20

DALI - PUSH - 1-10V - TRIAC - Max 1 module

Ceiling driver / Driver da sof

fitto

Matt White

Input 110-240V - 50/60Hz - Output 24V - 60W - IP20

DALI - PUSH - 1-10V - TRIAC - Max 3 module

MAGIA

MAGIA SIDE

19W

24V DC

2700K - 1272lm / 3000K - 1312lm

CRI >90

Driver not included

MAGIA DOWN

19W

24V DC

2700K - 1272lm / 3000K - 1312lm

CRI >90

Driver not included

Polished Gold - 2700K

Polished Gold - 3000K

Polished Black Chrome - 2700K

Polished Black Chrome - 3000K

Polished Gold - 2700K

Polished Gold - 3000K

Polished Black Chrome - 2700K

Polished Black Chrome - 3000K

1A5761900.27.20

1A5761900.30.20

1A5762800.27.20

1A5762800.30.20

1A5771900.27.20

1A5771900.30.20

1A5772800.27.20

1A5772800.30.20

1X0020400.01.00

1A4730000.00.00

Remote driver / Alimentatore remoto

100-240V

24V/50W/IP20/ON/OFF - Max 1 module

Remote driver / Alimentatore remoto

100-240V

24V/80W/IP20/ON/OFF - Max 3 modules

Remote driver / Alimentatore remoto

1A4780300.00.05

1A4740300.00.05

1Z1120490

1Z1120440

1Z1120500

1Z2170010

1X0050300.01.00

Not included

Not included

Not included

Not included

Not included

Not included

Not included

100-240V

Controller

Optional accessories / Accessori opzionali

24V/150W/IP67/1-10V

DALI - PUSH - 0/1-10V - TRIAC - IP20

Max 6 modules

Wall adapter plate / Piastra di adattamento da parete

Compulsory accessories / Accessori obbligatori

Wire guide / Guidacavo

Matt Black

1 Piece

Not included

Not included

Not included

Not included

Matt White

For mounting on brick masonry walls

Unipolar wire - 6 m / Cavo unipolare - 6 m

1 Piece - Max 60V DC

Max 3 modules

Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm

Matt White

For electrical cables - 1 Piece - Plasterboard cut-out Ø 44 mm

Minimum space for mounting 70 mm

Matt Black

For electrical cables - 1 Piece - Plasterboard cut-out Ø 44 mm

Minimum space for mounting 70 mm

Ceiling suspension kit / Kit di sospensione da soffitto

1X0000300.02.00

1X0000400.02.00

1X0010300.02.00

1X0010400.02.00

Matt White

Matt Black

For electrical cables - 1 Piece

For electrical cables - 1 Piece
