WALL HUNG FURNITURE

WALL HUNG FURNITURE

INFORMATION

Dimensions

& Technical Drawings:

Dimensional drawings

and technical

details are shown at

burlingtonbathrooms.com/

furniture

Tap holes:

Minerva® worktops are

supplied with an integrated

bowl with overflow, and no tap

holes. Tap holes are drilled by

the installer in the required

position and configuration. A

template is provided with the

Minerva® tops indicating tap

hole positions and sizes.

134 & 100 Curved Wall Units

134 & 100 CURVED WALL UNITS

Complete Vanity Unit Sizes

Vanity Unit Codes & Colours

Complete Unit

Type

Width

Depth

Height

+Splash

Matt White

Code

Sand

Olive

Code

Code

134 Curved wall-hung

vanity unit & Minerva®

3 Door

134

55

51

59

White with vanity bowl

FW4W +BW13

FW4S +BW13

FW4O +BW13

(A)

134 Curved wall-hung vanity

unit & Minerva® Black

3 Door

134

55

51

59

Granite with vanity bowl

FW4W +BB13

FW4S +BB13

FW4O +BB13

(B)

134 Curved wall-hung vanity

unit & Minerva® Carrara

3 Door

134

55

51

59

White with vanity bowl

FW4W +BC13

FW4S +BC13

FW4O +BC13

(C)

100 Curved wall-hung left

handed vanity unit with

drawer & Minerva® White

with left hand vanity bowl

LH 2 Door

98

55

51

59

FW5W +BW98L

FW5S +BW98L

FW5O +BW98L

(D)

100 Curved wall-hung left

handed vanity unit with

drawer & Minerva® Black

LH 2 Door

98

55

51

59

Granite with left hand

vanity bowl

FW5W +BB98L

FW5S +BB98L

FW5O +BB98L

100 Curved wall-hung

left handed vanity unit

with drawer & Minerva®

LH 2 Door

98

55

51

59

Carrara White with left

hand vanity bowl

FW5W +BC98L

(E)

FW5S +BC98L

FW5O +BC98L

100 Curved wall-hung right

handed vanity unit with

doors & Minerva® White

RH 2 Door

98

55

51

59

with right handed vanity

bowl

FW6W +BW98R

FW6S +BW98R

FW6O +BW98R

100 Curved wall-hung right

handed vanity unit with

doors & Minerva® Black

RH 2 Door

98

55

51

59

Granite with right handed

vanity bowl

FW6W +BB98R

FW6S +BB98R

(F)

FW6O +BB98R

100 Curved wall-hung right

handed vanity unit with

doors & Minerva® Carrara

RH 2 Door

98

55

51

59

White with right hand

vanity bowl

FW6W +BC98R

FW6S +BC98R

FW6O +BC98R

88

burlingtonbathrooms.com

All measurements shown are represented in cm

89

134 & 100 Curved

Wall Units

Curved cabinets come in either a centre design or left or right handed

options to place in corners for further flexibility. Pair yours with the

10cm splash-back provided to offer greater protection to your paint-work,

wallpaper or grouting. Every furniture piece features exquisitely crafted

brass handles for a delicate vintage feel of superior quality.

3 COLOURS

Sand, Matt White

& Dark Olive

S

W

O

*To order the correct furniture

colour simply remove the ‘z’

from the product code and

replace it with:

S for Sand (ie FF8S)

O for Dark Olive (ie FF8O)

W for Matt White (ie FF8W)

Above top; Sand Wall Hung 134 Curved Vanity unit,

134cm x 55cm Minerva White with one integrated

basin with one tap hole, Chelsea Curved Basin Mixer

with pop up waste, Matt White 90cm Mirror without

LED.

Above bottom; Dark Olive Right Handed Wall

Hung 100 Curved Corner Vanity Unit, 98cm x

55cm Minerva Carrara White with right handed

integrated basin with three tap holes, Anglesey

three tap hole basin mixer with pop up waste, Dark

Olive 90cm Mirror without LED.

Left hand

Left hand

Right hand

(A)

(B)

(C)

(D)

(E)

(F)
