SHOWERING

SHOWERING

Sliding Doors

Sliding Doors with Side Panels

1700mm Sliding Door (with In line panels) & 800mm Side Panel

10

On all showers

See website for details

1200mm Sliding door

Soft-close sliding door

Soft-close sliding door with side panel

Size

1100 x 700

1100 x 760

1100 x 800

1100 x 900

1200 x 700

1200 x 760

1200 x 800

1200 x 900

1400 x 800

1400 x 900

Adjustment

min-max

1070-1090

1070-1090

1070-1090

1070-1090

1170-1190

1170-1190

1170-1190

1170-1190

1370-1390

1370-1390

Enclosure

Tray

Code

Code

BU68 (C6S)

Z1169

BU68 (C6S)

Z1170

BU68 (C6S)

Z1171

BU68 (C6S)

Z1172

BU69 (C7S)

Z1173

BU69 (C7S)

Z1174

BU69 (C7S)

Z1175

BU69 (C7S)

Z1176

BU70 (C8S)

Z1177

BU70 (C8S)

Z1178

Size

*

1100 x 700

1100 x 760

1100 x 800

1100 x 900

1200 x 700

1200 x 760

1200 x 800

1200 x 900

1400 x 800

1400 x 900

Adjustment

min-max

1070-1090, 670-690

1070-1090, 730-750

1070-1090, 770-790

1070-1090, 870-890

1170-1190, 670-690

1170-1190, 730-750

1170-1190, 770-790

1170-1190, 870-890

1370-1390, 770-790

1370-1390, 870-890

Enclosure

Code

BU74 (C6S+C11)

BU75 (C6S+C12)

BU76 (C6S+C13)

BU77 (C6S+C14)

BU78 (C7S+C11)

BU79 (C7S+C12)

BU80 (C7S+C13)

BU81 (C7S+C14)

BU82 (C8S+C13)

BU83 (C8S+C14)

Tray

Code

Z1169

Z1170

Z1171

Z1172

Z1173

Z1174

Z1175

Z1176

Z1177

Z1178

*All enclosures are 1950 high

and adjustable up to 20mm from

each wall.

All shower posts are constructed

from aluminium and can be

installed with or without chrome

ball header. Safety glass is 8mm

thick and 3MTM easy clean coating.

Soft-close mechanisms are

supplied with the door and can be

fitted as an option.

Shower tray prices exclude waste

Z1205

Soft-close sliding door with in-line panel

Soft-close sliding door with in-line and side panel

Size

1500 x 700

1500 x 760

1500 x 800

1600 x 700

1700 x 700

1700 x 760

1700 x 800

Adjustment

min-max

1470-1490

1470-1490

1470-1490

1570-1590

1670-1690

1670-1690

1670-1690

Enclosure

Tray

Code

Code

BU71 (C7S+C16)

Z1179

BU71 (C7S+C16)

Z1180

BU71 (C7S+C16)

Z1181

BU72 (C8S+C15)

Z1182

BU73 (C8S+C16)

Z1183

BU73 (C8S+C16)

Z1184

BU73 (C8S+C16)

Z1185

soft

Size*

1500 x 700

1500 x 760

1500 x 800

1600 x 700

1700 x 700

1700 x 760

1700 x 800

Adjustment

min-max

1470-1490, 670-690

1470-1490, 730-750

1470-1490, 770-790

1570-1590, 670-690

1670-1690, 670-690

1670-1690, 730-750

1670-1690, 770-790

Enclosure

Code

BU84 (C7S+C16+C11)

BU85 (C7S+C16+C12)

BU86 (C7S+C16+C13)

BU87 (C8S+C15+C11)

BU88 (C8S+C16+C11)

BU89 (C8S+C16+C12)

BU90 (C8S+C16+C13)

Tray

Code

Z1179

Z1180

Z1181

Z1182

Z1183

Z1184

Z1185

soft

174

burlingtonbathrooms.com

All measurements shown are represented in cm

175

A: Slider

B: In-line panel

A: Slider

B: In-line panel

C: Side panel

Sliding door

A

A

Sliding door with side panel

B

A

Sliding door with in-line panel

*This indicates depth of matching tray size

available for use in a recessed installation.

All enclosures are 1950 high and adjustable

up to 20mm from each wall.

All shower posts are constructed from

aluminium and can be installed with or

without chrome ball header. Safety glass is

8mm thick and 3MTM easy clean coating.

Soft-close mechanisms are supplied with

the door and can be fitted as an option.

Shower tray prices exclude waste

Z1205

B

A

B

Sliding door with in-line and side panel

close

close

C

C
