HOUSINGS DP BIG

FOR CARTRIDGES BIG SX

Mono, Duo and Trio patented and registered models.

The all new, most comprehensive range of housings fit to 10” and 20” BIG filter

cartridges with outer diameter 4,50”, with standard SX (DOE) configuration.

A wide range of BIG filter cartridges melt-blown polypropylene, string wound, carbon

block and brand new pleated media is available for the housing range.

DP BIG models are available as:

- CLEAR housings 10” and 20”, with female in/out connections at 1” and 1”1/2 with BSP or NPT

threads.

- BLUE housings 10” and 20”, with female in/out connections at 1” and 1”1/2 with BSP or NPT

threads.

All housings, clear and opaque, are also available as models with manometers and with

discharge valve provided with drain funnel to protect drinking water from pollution by back-wash,

in compliance with UNI EN 1717-11/2002.

ACCESSORIES ON DEMAND

1” brass nipples

with o-ring (pair)

CODE RB7404002

-DP BIG MONO-

wall bracket

CODE RB7401040

CERTIFICATIONS

Housings certified by IAPMO RT to NSF/ANSI 42, 61, 372

- lead free, CSA B483.1. In compliance with Drinking Water

Treatment Units regulations, USA and Canada.

Housings are tested and certified under the most stringent

procedures worldwide, in compliance with DM 25 (Italy),

with the sanitary certification EAC/Ghostreghistrazia

(Russia) and WaterMark (Australia).

-DP BIG- spanner

CODE RB7403019

DISCHARGE KIT FOR -S- MODEL

brass discharge ball-valve with gasket

drain funnel

plastic hose-holder

In compliance with the European Standard UNI EN

1717/2002: designed to prevent back-flow contamination

by making all elements downstream the discharge vent to

atmosphere (protection unit symbol: DC)

SYMBOLS LEGEND

For domestic use

For technical and

industrial use

M

E

Filter housings made in PET, a

ATLAS

highly recyclable plastic, are

green

manufactured with a proprietary

procedure saving up to 60% of

R

I

energy in injection molding

compared with standard plastics. That is one of Atlas

Filtri commitments to comply with Kyoto Treaty for

the reduction of green house gas (CO

2

) emissions in

-LUBRIKIT- single-dose lubricant for housing o-ring

the atmosphere.

CODE RE9020650

118 | DP BIG filter housings

SX

cartridges

with standard flat seals.

ACCESSORIES INCLUDED

-DP BIG DUO- wall bracket

CODE RB7401043

-DP BIG TRIO- wall bracket

CODE RB7401044

-KIT AUTO- for S models

CODE RE7120024

automatic discharge kit (see pages 186-187)

-KIT LEG 10- for DP BIG 10

-KIT LEG 20- for DP BIG 20

CODE RB7401051

CODE RB7401052

-KIT FRAME 10 MONO-

-KIT FRAME 20 MONO-

for DP BIG 10 MONO

for DP BIG 20 MONO

CODE RB7401045

CODE RB7401046

-KIT FRAME 10 DUO-

-KIT FRAME 20 DUO-

for DP BIG 10 DUO

for DP BIG 20 DUO

CODE RB7401047

CODE RB7401048

-KIT FRAME 10 TRIO-

-KIT FRAME 20 TRIO-

for DP BIG 10 TRIO

for DP BIG 20 TRIO

CODE RB7401049

CODE RB7401050

-VT- ground fixing kit

CODE LB7221134
