DP BIG DUO
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
Max working pressure ______8,3 bar (120 psi)
Max working temperature _______45°C (113°F)
Min working temperature________4°C (39,2°F)
Non-toxic materials, suitable for drinking water.
Head: reinforced polypropylene.
Clear bowl: PET.
Blue bowl: reinforced polypropylene.
O-ring: EPDM.
Breather-valve: body polypropylene, o-ring EPDM.
DP BIG DUO clear housings
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA1802711
RA1802911
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
DIMENSIONS mm
RA1702711
RA1702911
RA1702721
RA1702921
RA1702712
RA1702912
RA1702722
RA1702922
DP BIG 10 DUO - 1” IN TS
DP BIG 10 DUO - 1”1/2 IN TS
DP BIG 20 DUO - 1” IN TS
DP BIG 20 DUO - 1”1/2 IN TS
DP BIG 10 DUO - 1” NPT IN TS
DP BIG 10 DUO - 1”1/2 NPT IN TS
DP BIG 20 DUO - 1” NPT IN TS
DP BIG 20 DUO - 1”1/2 NPT IN TS
DP BIG 10 DUO - 1” IN AB
DP BIG 10 DUO - 1”1/2 IN AB
DP BIG 20 DUO - 1” IN AB
DP BIG 20 DUO - 1”1/2 IN AB
DP BIG 10 DUO - 1” NPT IN AB
DP BIG 10 DUO - 1”1/2 NPT IN AB
DP BIG 20 DUO - 1” NPT IN AB
DP BIG 20 DUO - 1”1/2 NPT IN AB
10”
10”
20”
20”
10”
10”
20”
20”
10”
10”
20”
20”
10”
10”
20”
20”
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
A
B
C
185
185
375
375
640
640
375
375
640
640
375
375
640
640
375
375
640
640
390
390
390
390
390
390
390
390
390
390
390
390
390
390
390
185
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA1802721
RA1802921
MODEL
DIMENSIONS mm
A
B
C
185
185
185
185
DP BIG DUO blue housings
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA1802712
RA1802912
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
DIMENSIONS mm
A
B
C
185
185
185
185
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA1802722
RA1802922
MODEL
DIMENSIONS mm
A
B
C
185
185
185
185
125 | DP BIG filter housings
390
185
