PLUS S 3P BX
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
32 | PLUS filter housings
Max working pressure:
BSP versions ____________8 bar (116 psi)
NPT versions ___________8,6 bar (125 psi)
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
DRAIN FUNNEL
Back-flow
preventing device
UNI EN 1717-11/2002
Non-toxic materials, suitable for drinking water.
Head and ring nut: reinforced polypropylene.
Bowl: PET.
O-ring: EPDM.
Breather-valve: body polypropylene, o-ring EPDM.
IN/OUT brass threads: CW 617 N brass.
Discharge ball-valve: CW 617 N brass nickel plated.
Discharge plastic nipple: reinforced polypropylene.
Drain funnel: reinforced polypropylene.
➝
PLUS S 3P BX clear housings with discharge valve
HOUSINGS WITH BRASS BSP THREADS
CODE
RA115T123
RA115T428
RA115T725
MODEL
SUITABLE
CARTRIDGE
IN/OUT
DIMENSIONS mm
RA111T123
RA111T428
RA111T726
RA111T127
RA111T527
RA111T827
RA111T433
RA111T733
RA111T130
RA111T430
RA111T730
SENIOR PLUS S 3P MFO BX TS
SENIOR PLUS S 3P AFO BX TS
SENIOR PLUS S 3P BFO BX TS
MASTER PLUS S 3P MFO BX TS
MASTER PLUS S 3P AFO BX TS
MASTER PLUS S 3P BFO BX TS
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA115T127
RA115T527
RA115T727
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
IN/OUT
DIMENSIONS mm
SENIOR PLUS S 3P MFP BX TS
SENIOR PLUS S 3P AFP BX TS
SENIOR PLUS S 3P BFP BX TS
MASTER PLUS S 3P MFP BX TS
MASTER PLUS S 3P AFP BX TS
MASTER PLUS S 3P BFP BX TS
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA115T433
RA115T733
MODEL
DIMENSIONS mm
SENIOR PLUS S 3P AFP NPT BX TS
SENIOR PLUS S 3P BFP NPT BX TS
MASTER PLUS S 3P AFP NPT BX TS
MASTER PLUS S 3P BFP NPT BX TS
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA115T130
RA115T430
RA115T730
MODEL
DIMENSIONS mm
SENIOR PLUS S 3P MMP BX TS
SENIOR PLUS S 3P AMP BX TS
SENIOR PLUS S 3P BMP BX TS
MASTER PLUS S 3P MMP BX TS
MASTER PLUS S 3P AMP BX TS
MASTER PLUS S 3P BMP BX TS
Some items in the list are subject to minimum order quantities and/or to longer delivery term.
