housings PLUS 3P for cartridges BX and CX
P
L
U
S
F
I
L
T
E
R
H
O
U
S
I
N
G
S
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
Max working pressure:
BSP versions ____________8 bar (116 psi)
NPT versions ___________8,6 bar (125 psi)
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
Non-toxic materials, suitable for drinking water.
Head and ring nut: reinforced polypropylene.
Bowl: PET.
O-ring: EPDM.
Breather-valve: body polypropylene, o-ring EPDM.
IN/OUT brass threads: CW 617 N brass.
DUPLEX PLUS 3P BX blue housings
HOUSINGS WITH BRASS BSP THREADS
CODE
RA110T422
RA110T722
RA116T422
RA116T722
MODEL
SUITABLE
CARTRIDGE
IN/OUT
DIMENSIONS mm
RA108T422
RA108T722
RA112T422
RA112T722
RA108T522
RA112T522
RA108T426
RA112T622
MEDIUM DUPLEX PLUS 3P AFO BX AB
MEDIUM DUPLEX PLUS 3P BFO BX AB
JUNIOR DUPLEX PLUS 3P AFO BX AB
JUNIOR DUPLEX PLUS 3P BFO BX AB
SENIOR DUPLEX PLUS 3P AFO BX AB
SENIOR DUPLEX PLUS 3P BFO BX AB
MASTER DUPLEX PLUS 3P AFO BX AB
MASTER DUPLEX PLUS 3P BFO BX AB
MEDIUM DUPLEX PLUS 3P AFP BX AB
JUNIOR DUPLEX PLUS 3P AFP BX AB
SENIOR DUPLEX PLUS 3P AFP BX AB
MASTER DUPLEX PLUS 3P AFP BX AB
MEDIUM DUPLEX PLUS 3P AFP NPT BX AB
JUNIOR DUPLEX PLUS 3P AFP NPT BX AB
SENIOR DUPLEX PLUS 3P AFP NPT BX AB
MASTER DUPLEX PLUS 3P AFP NPT BX AB
5”
5”
7”
7”
10”
10”
20”
20”
5”
7”
10”
20”
5”
7”
10”
20”
3/4”
1”
3/4”
1”
3/4”
1”
3/4”
1”
3/4”
3/4”
3/4”
3/4”
3/4”
3/4”
3/4”
3/4”
A
B
C
130
130
130
130
191
191
241
241
315
315
571
571
191
241
315
571
191
241
315
571
275
275
275
275
275
275
275
275
275
275
275
275
275
275
275
275
130
130
130
130
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA110T522
RA116T522
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
DIMENSIONS mm
A
B
C
130
130
130
130
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA110T426
RA116T622
MODEL
DIMENSIONS mm
A
B
C
130
130
130
130
Some items in the list are subject to minimum order quantities and/or to longer delivery term.
35 | PLUS filter housings
