ATLAS
green
R
I
K DP S
only for BX cartridges
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
B
C
A
Max working pressure ______10 bar (145 psi)
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
DRAIN FUNNEL
Back-flow
preventing device
UNI EN 1717-11/2002
K DP S housings with discharge valve
HOUSINGS WITH BRASS BSP THREADS
Non-toxic materials, suitable for drinking water.
Head and ring nut: CB 753 S brass.
Bowl: PET.
O-ring: EPDM.
Breather-valve: CW 614 N brass.
Discharge ball-valve: CW 617 N brass nickel plated.
Discharge plastic nipple: reinforced polypropylene.
Drain funnel: reinforced polypropylene.
Manometers: radial type, pressure range 0-12 bar, 0-170 psi.
CODE
RA3250425
RA3250725
RA3251035
RA3251135
MODEL
SUITABLE
CARTRIDGE
IN/OUT
DIMENSIONS mm
K DP S M
only for BX cartridges
K DP S M housings with discharge valve and 2 manometers
HOUSINGS WITH BRASS BSP THREADS
CODE
RA3250427
RA3250727
RA3253035
RA3253135
MODEL
SUITABLE
IN/OUT
CARTRIDGE
DIMENSIONS mm
A
B
C
105
105
105
105
A
B
C
105
105
105
105
75 | special filter housings
➝
RA3210425
K1 DP SENIOR S AFO SX/BX
10”
3/4”
485
120
105
RA3210725
K2 DP SENIOR S BFO SX/BX
10”
1”
485
120
105
RA3211035
K3 DP SENIOR S CFO CX
10”
1”1/2
495
130
105
RA3211135
K4 DP SENIOR S DFO CX
10”
2”
505
130
105
K1 DP MASTER S AFO SX/BX
20”
3/4”
740
120
K2 DP MASTER S BFO SX/BX
20”
1”
740
120
K3 DP MASTER S CFO CX
20”
1”1/2
750
130
K4 DP MASTER S DFO CX
20”
2”
755
130
RA3210427
K1 DP SENIOR S M AFO SX/BX
10”
3/4”
530
120
105
RA3210727
K2 DP SENIOR S M BFO SX/BX
10”
1”
530
120
105
RA3213035
K3 DP SENIOR S M CFO CX
10”
1”1/2
540
130
105
RA3213135
K4 DP SENIOR S M DFO CX
10”
2”
550
130
105
K1 DP MASTER S M AFO SX/BX
20”
3/4”
785
120
K2 DP MASTER S M BFO SX/BX
20”
1”
785
120
K3 DP MASTER S M CFO CX
20”
1”1/2
795
130
K4 DP MASTER S M DFO CX
20”
2”
800
130
