housings DP for cartridges SX and BX
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
92 | DP filter housings
Max working pressure:
BSP versions ____________8 bar (116 psi)
NPT versions ___________8,6 bar (125 psi)
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
Non-toxic materials, suitable for drinking water.
Head: reinforced polypropylene.
Bowl: PET.
O-ring: EPDM.
IN/OUT brass threads: CW 617 N brass.
Manometers: radial type, pressure range 0-12 bar, 0-170 psi.
DP M MONO white housings with 2 manometers
HOUSINGS WITH BRASS BSP THREADS
CODE
MODEL
RA1351336
RA1351436
RA1351736
RA1351836
RA1351936
RA1381336
RA1381436
RA1381736
RA1381836
RA1381936
HOUSINGS WITH PLASTIC BSP THREADS
CODE
MODEL
RA1351356
RA1351456
RA1351756
RA1381356
RA1381456
RA1381756
HOUSINGS WITH PLASTIC NPT THREADS
CODE
MODEL
RA1351446
RA1351746
RA1381446
RA1381746
VARIANTS AVAILABLE ON MINIMUM QUANTITY:
SUITABLE
IN/OUT
DIMENSIONS mm
CARTRIDGE
A
B
C
107
107
107
107
107
107
107
107
107
107
RA1350336
DP M 5 MONO 1/2” OT BW
5”
1/2”
232
122
107
RA1350436
DP M 5 MONO 3/4” OT BW
5”
3/4”
232
122
107
RA1350736
DP M 5 MONO 1” OT BW
5”
1”
232
122
107
RA1350836
DP M 5 MONO 1”1/4 OT BW
5”
1”1/4
267
124
107
RA1350936
DP M 5 MONO 1”1/2 OT BW
5”
1”1/2
267
124
107
DP M 7 MONO 1/2” OT BW
7”
1/2”
280
122
DP M 7 MONO 3/4” OT BW
7”
3/4”
280
122
DP M 7 MONO 1” OT BW
7”
1”
280
122
DP M 7 MONO 1”1/4 OT BW
7”
1”1/4
313
124
DP M 7 MONO 1”1/2 OT BW
7”
1”1/2
313
124
RA1380336
DP M 10 MONO 1/2” OT BW
10”
1/2”
372
122
107
107
107
107
107
RA1380436
DP M 10 MONO 3/4” OT BW
10”
3/4”
372
122
RA1380736
DP M 10 MONO 1” OT BW
10”
1”
372
122
RA1380836
DP M 10 MONO 1”1/4 OT BW
10”
1”1/4
390
124
RA1380936
DP M 10 MONO 1”1/2 OT BW
10”
1”1/2
390
124
DP M 20 MONO 1/2” OT BW
20”
1/2”
632
122
DP M 20 MONO 3/4” OT BW
20”
3/4”
632
122
DP M 20 MONO 1” OT BW
20”
1”
632
122
DP M 20 MONO 1”1/4 OT BW
20”
1”1/4
643
124
DP M 20 MONO 1”1/2 OT BW
20”
1”1/2
643
124
SUITABLE
IN/OUT
DIMENSIONS mm
CARTRIDGE
A
B
C
107
107
107
107
107
107
RA1350356
DP M 5 MONO 1/2” IN BW
5”
1/2”
232
122
107
RA1350456
DP M 5 MONO 3/4” IN BW
5”
3/4”
232
122
107
RA1350756
DP M 5 MONO 1” IN BW
5”
1”
232
122
107
DP M 7 MONO 1/2” IN BW
7”
1/2”
280
122
DP M 7 MONO 3/4” IN BW
7”
3/4”
280
122
DP M 7 MONO 1” IN BW
7”
1”
280
122
RA1380356
DP M 10 MONO 1/2” IN BW
10”
1/2”
372
122
107
107
107
RA1380456
DP M 10 MONO 3/4” IN BW
10”
3/4”
372
122
RA1380756
DP M 10 MONO 1” IN BW
10”
1”
372
122
DP M 20 MONO 1/2” IN BW
20”
1/2”
632
122
DP M 20 MONO 3/4” IN BW
20”
3/4”
643
122
DP M 20 MONO 1” IN BW
20”
1”
643
122
SUITABLE
IN/OUT
DIMENSIONS mm
CARTRIDGE
A
B
C
107
107
107
107
RA1350446
DP M 5 MONO 3/4” NPT IN BW
5”
3/4”
232
122
107
RA1350746
DP M 5 MONO 1” NPT IN BW
5”
1”
232
122
107
DP M 7 MONO 3/4” NPT IN BW
7”
3/4”
280
122
DP M 7 MONO 1” NPT IN BW
7”
1”
280
122
RA1380446
DP M 10 MONO 3/4” NPT IN BW
10”
3/4”
372
122
107
107
RA1380746
DP M 10 MONO 1” NPT IN BW
10”
1”
372
122
DP M 20 MONO 3/4” NPT IN BW
20”
3/4”
643
122
DP M 20 MONO 1” NPT IN BW
20”
1”
643
122
Some items in the list are subject to minimum order quantities and/or to longer delivery term.
- RT housings suitable for filter cartridges
with length 508 mm
