782
Shower enclosures / 3 walls / Front / Swing doors
Parois de douche / 3 murs / Frontale / Portes battantes
Shower enclosures / 2 walls / Front / Sliding doors
Parois de douche / 2 murs / Frontale / Portes coulissantes
1950
1950
Ura L4-E + LF-C
B
A
Ura PE
C
A
PE - Frontal swing door. To install between walls or with 1 side panel LF. Clear glass and
polished silver profile. Compensating profile 25 mm. MaxiClean treatment included.
PE - Paroi frontale 1 porte battant. Possibilité de montage entre murs ou avec un côté fixe
LF. Verre transparent et profilé chromé brillant. Compensation de 25 mm. Traitement
Maxiclean inclus.
L4-E – Front shower enclosure with 2 sliding doors + 2 fixed panels. To install between
walls or with 1 side panel LF. Clear glass and polished silver profile. Compensating profile
25 mm. MaxiClean treatment included.
LF - Side panel. To be combined with a L2-E or L4-E enclosure.
L4-E - Paroi frontale 2 panneaux fixes-2 panneaux coulissants - ouverture centrale.
Possibilité de montage avec 1 côté fixe en retour LF. Verre transparent. Profilé Argent
Brillant. Compensation de 25 mm. Traitement Maxiclean inclus.
LF - Panneau latéral. Pour combiner avec paroi L2-E ou L4-E.
Width (A)
AM16708012M
800
AM16709012M
900
AM16710012M
1000
1950
Victoria PE
Opening
650
750
850
Width (A)
L4-E
A
Opening (C)
610
660
710
710
710
AM16316012M
AM16317012M
AM16318012M
AM16319012M
AM16320012M
1600
1700
1800
1900
2000
A
LF(B)
B
AM16407012M
700
AM16407512M
750
AM16408012M
800
AM16409012M
900
PE - Frontal swing door. To install between walls or with 1 side panel LF. Clear glass and
polished silver profile. Compensating profile 25 mm.
PE - Paroi frontale 1 porte battant. Possibilité de montage entre murs ou avec un côté fixe
LF. Verre transparent et profilé chromé brillant. Compensation de 25 mm.
Width (A)
AM19107012
AM19108012
AM19109012
Victoria 2P
2P - Frontal 2 swing doors.
700
800
900
1950
180o
180o
A
2P - Paroi frontale avec 2 battants.
Width (A)
AM19208012
800
AM19209012
900
Dimensions in mm.
Dimensions en mm.
