VRF - Sistemi a Flusso Refrigerante Variabile - Variable Refrigerant Flow

TPV MINI VRF FULL DC INVERTER - R410a

A BASSA CAPACITÁ

SMALL CAPACITY

LUNGHEZZA DELLE LINEE E DIFFERENZA D’ALTEZZA

LINE LENGTH & HEIGHT DIFFERENCE

• Lunghezza totale linea: 100 m (monofase 8-16 kW) 120 m (trifase

12,5-33,5 kW)

• Lunghezze massime:

1. Lunghezza attuale: 60 m

2. Lunghezza equivalente: 70 m

• Lunghezza equivalente dal primo distributore all’ultima unità interna:

20 m

• Differenza d’altezza tra unità interna ed esterna:

1. Quando l’unità esterna è superiore: <30m

2. Quando l’unità esterna é inferiore: <20 m

• Max. differenza d’altezza tra le unità interne: 8 m

• Total pipe length: 100 m (single-phase 8-16 kW) 120m (three-phase

12,5-33,5 kW)

• Max. Lenghts:

1. Actual length 60 m

2. Equivalent length 70 m

• Equivalent length from first indoor distributor to last indoor unit: 20 m

• Height difference between indoor and outdoor unit:

1. Outdoor unit is above < 30 m

2. Outdoor unit is below < 20 m

• Max. Height difference between indoor units: 8 m

COMPRESSORE DC INVERTER AD ALTA EFFICIENZA

HIGH EFFICIENCY DC INVERTER COMPRESSOR

• Compressore twin-rotary DC inverter

• Compressore ad alta efficienza e affidabilità

• Ottima efficienza in condizioni di carico parziale

• Basso rumore

• Protezione ambientale

• Basse vibrazioni

• Twin-rotary DC inverter compressor

• High efficiency and reliability compressor

• Very good efficiency in part load condition

• High efficiency, low noise

• Environmental protection

• Low vibration

RAFFREDDAMENTO E RISCALDAMENTO RAPIDO

FAST COOLING AND HEATING

• Bassa rumorosità e alta efficienza grazie all’avvolgimento del filo ad

alta densità

• Senza spazzole con sensore incorporato

• Ogni stanza raggiunge rapidamente la tempertura desiderata grazie

al controllo del refrigerante ottimizzato

• Low noise and high efficiency thanks to the high density wire winding

• Brushless with built-in sensor

• Each room quickly reaches the desired temperature thanks to

optimized refrigerant control

S

I

S

T

E

M

I

V

R

F

A PROPOSITO DI TPV MINI

ABOUT TPV MINI
