Pumps
45
Pumps
Hya-Solo D FL
Hya-Duo D FL
Rp
1 Description
Hya-Solo D FL Compact
Hya-Duo D FL Compact
DN
Q [m
3
/h]
H [m]
p [bar]
T [°C]
Surpress Feu SFE
Rp
Q [m
3
/h]
H [m]
p [bar]
T [°C]
≥ 0
Data for 50 Hz operation
≥ 0
Data for 50 Hz operation
-
-
2 1/2
≤ 40
≤ 76
≤ 10
≤ +70
DN
100
Fully automatic package single-pump system. The system is started and
stopped as a function of pressure. Design and function as per DIN 14462.
Applications
Fire-fighting systems to DIN 14462
http://shop.ksb.com/catalog/k0/en/product/ES000709
Description
Fully automatic package dual-pump system consisting of one duty system and
one stand-by system to ensure system redundancy. Design and function as per
DIN 14462.
Applications
Fire-fighting systems to DIN 14462
http://shop.ksb.com/catalog/k0/en/product/ES000710
Description
Fully automatic ready-to-connect break tank package booster set for fire
fighting, comprising a single-pump system and break tank. The system is
started and stopped as a function of pressure. Design and function as per
DIN 14462.
Applications
Fire-fighting systems to DIN 14462
http://shop.ksb.com/catalog/k0/en/product/ES000821
Description
Fully automatic ready-to-connect break tank package booster set for fire
fighting, comprising one duty system and one stand-by system to ensure
system redundancy. The system is started and stopped as a function of
pressure. Design and function as per DIN 14462.
Applications
Fire-fighting systems to DIN 14462
http://shop.ksb.com/catalog/k0/en/product/ES000820
Description
Fully automatic pressure booster system with two horizontal close-coupled
pumps (one pump on stand-by duty). Design complies with APSAD
regulation R5. Pressure-controlled starting and stopping. Automated with
BoosterControl.
Applications
Water supply and pressure boosting for wall hydrants, fire protection.
http://shop.ksb.com/catalog/k0/en/product/ES000441
Q [m
3
/h]
H [m]
p [bar]
T [°C]
Rp
DN
Q [m
3
/h]
H [m]
p [bar]
T [°C]
≥ 0
Data for 50 Hz operation
≥ 0
Data for 50 Hz operation
-
-
≤ 110
≤ 160
≤ 16
≤ +70
2
150
≤ 110
≤ 160
≤ 16
≤ +70
DN
Q [m
3
/h]
H [m]
p [bar]
T [°C]
≥ 0
Data for 50 Hz operation
50 - 80
≤ 48
≤ 160
≤ 16
- ≤ +70
50 - 80
≤ 48
≤ 160
≤ 16
≤ +70
