Tubazioni in acciaio CSST per impianti gas

Steel PLT-CSST tubes for gas installations

Tubi CSST EUROGAS in acciaio inox AISI 316L (1.4404

EN 10028-7) a norma UNI EN 15266

Tubi corrugati formabili CSST (Corrugated Stainless Steel

Tubing) in acciaio INOX AISI 316L* per trasporto di gas con ri-

vestimento protettivo giallo in LDPE. Le tubazioni CSST EU-

ROGW/EUROGAS di Eurotis sono conformi alla norma euro-

pea EN 15266 e sono idonei per impianti gas della I° famiglia

(gas di città), II° famiglia (gas naturale: metano) e III° famiglia

(GPL). Per assicurare la tenuta devono essere utilizzate uni-

camente le guarnizioni in NBR o HNBR a norma EN 682 per

gas fornite da Eurotis.

AISI 316L (EN 1.4404 EN 10028-7) EUROGAS stainless

steel PLT-CSST tubes conform to EN 15266 standard

Corrugated pliable PLT-CSST (Corrugated Stainless Steel

Tubing) tubes in AISI 316L* stainless steel for gas supply with

LDPE protective yellow coating. EUROGW/EUROGAS PLT-

CSST tubes by Eurotis are conform to EN 15266 European

standard and are suitable for gas plants of the I° family (city

gas), II° family (natural gas: methane) and III° family (LPG). To

assure tightness use only NBR or HNBR gaskets conform to

EN 682 standard for gas supplied by Eurotis.

*AISI 316L (designazione: 1.4404 - X2CrNiMo17-12-2): acciaio inossidabile

austenitico conforme alla norma EN 10028-7.

*AISI 316L (designation: 1.4404 - X2CrNiMo17-12-2): austenitic stainless

steel complying with EN 10028-7.

Tubi CSST EUROGAS in acciaio inox AISI 316L con rive-

stimento stellare

Nelle istallazioni sotto traccia la normativa italiana

UNI7129:2015 prevede che in presenza di pareti contenenti

cavit

à o nelle installazioni interrate le tubazioni CSST devo-

no essere inserite in una guaina. Eurotis propone la propria

gamma di tubazioni CSST per impianti gas gi

à inserite in ap-

posita guaina di colore giallo con particolare conformazione

denominata “stellare”. Questa tipologia di guaina protegge

il tubo, lo mantiene centrato e impedisce infiltrazioni di gas

nelle cavit

à della parete.

AISI 316L EUROGAS stainless steel PLT-CSST tubes with

stellar coating

In the under-ground installations, the italianlegislation

UNI7129:2015 states that in the presence of walls that contain

cavities or in underground installations, the PLT-CSST tubes

must be inserted in a sheath.Eurotis proposes its own range

of PLT-CSST tubes for gas installations already inserted in a

special yellow sheath with particular shape called “stellar”. This

type of sheath protects the tube, keeps it centered and pre-

vents infiltration of gas into the wall cavities.

Sistemi Eurotis / Eurotis systems 35
