Kessel - 4.1

132 3.1 Lifting stations

Accessories

Catalogue EN 4.1

Outer diameter

Ø (mm)

Ø 90

Ø 100

Ø 110

Ø 160

Outer diameter

Ø (mm)

Ø 90

Ø 110

KESSEL AG

Art. no.

28 715

28 716

28 682

28 683

28 698

28 699

Art. no.

28 713

28 712

Art. no.

28 680

Art. no.

28 714

Closure valves

Closure valve, vertical

Closure valve

with flange adaptor,

vertical

Closure valve

Connection flange

in PE

Compatibility: For lifting station

Aqualift F Basic, Aqualift F Mono / Duo

and Aqualift F XL

Function: For the pressure pipe of KESSEL lifting

stations with plastic fitting; for connection to

pressure pipe, a KESSEL flange connector or

adapter is required.

Inclusive: Gasket, screw

Compatibility: For lifting station

Aqualift F Basic, Aqualift F Mono / Duo

and Aqualift F XL

Function: For the pressure pipe of KESSEL lifting

stations with plastic fitting

Inclusive: With screwed flange adaptor, for

connection to a standard flange DN 80 according to

DIN 2501 (without sealing gasket and screw)

Compatibility: With lateral pressure pipe

for lifting stations Aqualift F

Compatibility: For installation on the inlet side

(no pressure) for lifting stations Aqualift F

Compatibility: For KESSEL plastic fittings;

for lifting station Aqualift F XL

Compatibility: For KESSEL plastic fittings;

for Aqualift F Basic and Aqualift F XL; also in

combination with closure valve Art. no. 28 715

Function: Spigot end for DN 100 pressure pipe

connection

Manual diaphragm pump 1 1/2 inch

Manual diaphragm

pump in cast iron

Flange adaptor

in PE

in cast iron

Compatibility: For manually pumping wastewater;

for lifting station Aqualift F Mono / Duo

and Aqualift F XL

Inclusive: With a ball valve on inlet and outlet side

Compatibility: From KESSEL fitting to standard

flange; for lifting station Aqualift F XL

Outer diameter

Ø (mm)

196

DN 80

160

Compatibility: For use with cast iron pressure pipes;

180

–

28068

for lifting station Aqualift F XL

Function: Adaptor from DN 80 to DN 100

Inclusive: Flange according to DIN 2501

160
