3.1 Lifting stations 133

Accessories

Backflow preventer

in cast iron

Compatibility: For lifting station Aqualift F XL

Inclusive: DN 80 flange according to DIN 2501,

backflow preventer with flap and flap opening lever

Connection adaptor

160

160

180

160

Outer diameter

Ø (mm)

DN 80

Outer diameter

Ø (mm)

Ø90

Ø 110

Outer diameter

Ø (mm)

DN 80

Outer diameter

Ø (mm)

Ø80

Outer diameter

Ø (mm)

DN 80

DN 100

Art. no.

28 021

Art. no.

28 067

28 020

Art. no.

28 041

Art. no.

28 042

Art. no.

28 043

28 044

28 078

in cast iron

Compatibility: For connection from lifting station

Aqualift F XL to on-site pressure pipe.

Fits PE pressure pipes

Inclusive: Flange according to DIN 2501,

single gasket

Outer diameter:

DN80:OD90mm

DN 100: OD 110 mm

Compatibility: For lifting station Aqualift F XL

Inclusive: DN 80 flange according to DIN 2501,

gate closure valve including closure wheel

Compatibility: For lifting station Aqualift F XL

Inclusive: DN 80 (OD 80 mm) flange

according to DIN 2501

Compatibility: Flange according to DIN 2501,

for pressure pipe connections; for lifting station

Aqualift F XL

Compatibility: For Art. no. 28 043 and 28 044

Inclusive: 4 bolts, 4 nuts, 8 washers

Gate closure valve

in cast iron

Y-Coupling

in cast iron

Sealing gasket

Sealing gasket

(rubber)

Bolt set M16
