The right cover

Drains, covers and upper sections must be installed in

such a way that they are able to cope with potential

loads at the place of installation. The two standards

EN 1253-1 (Gullies for buildings) and EN 124 (Gully tops

and manhole tops for vehicular and pedestrian areas).

In cases of doubt, the higher class must always be chosen.

Covers and upper sections to EN 1253-1

The right material

Drains are offered in a range of different

materials. Which material is used depends

on the requirements set by the type of

wastewater to be discharged.

Polymer (PP or ABS)

Drains made of polymer are generally

characterised by their high impact resistance,

light weight and simple design.

Ecoguss

Building drains made of the composite mate-

rial Ecoguss are naturally hygienic and highly

resistant to chemicals on account of the

smooth and corrosion-free surface. Additional

protective coatings are not necessary. Weight

approx. 70 % lower than cast iron drains, no

electrical grounding necessary and suitable

for installation in hot bitumen thanks to

high-temperature resistance properties.

Metal

Classic metal drains are hygienic, heat

resistant and generally load resistant. They

are therefore primarily suitable for extreme

conditions in commercial and industrial

premises.

Class H 1.5

Class K 3

Class L 15

Class R 50

Class M 125

Load class up to max. 150 kg

Unused roof space (no traffic)

Load class up to max. 300 kg

Areas without vehicular traffic, such as bathrooms at home, retirement

homes, hotels, schools, swimming baths, public washing and shower facilities,

balconies, loggias, terraces and green roofs.

Load class up to max. 1.5 t

Areas with light vehicular traffic such as cycleways and domestic drives.

Load class up to max. 5.0 t

Used roof space (roof parking area)

Load class up to max. 12.5 t

Areas with vehicular traffic, such as car parks, factories and workshops –

not including light commercial vehicles or heavy wheel loads.

Covers and upper sections to EN 124

Class A 15

Class B 125

Class C 250

Class D 400

Class E 600

Group 1 For use in areas where only pedestrians have access.

Group 2 For use in car parks and pedestrian areas where only occasional

vehicular access is likely.

Group 3 For use in car parks, forecourts, industrial sites and areas with slow

moving traffic also in highway locations up to 500 mm from the kerb and up

to 200 mm into the verge, excluding motorways.

Group 4 For use in areas where cars and lorries have access, including

carriageways, hard shoulders and pedestrian areas.

Group 5 For use in areas with heavy traffic - miliarty, airports, ports.

Lock & Lift

Our locking and removal device

Lock & Lift

allows drain covers to be removed

or inserted in seconds - significantly

reducing maintenance time.
