1.1 Backwater valves

Single flap backwater valve Staufix

Installation in a concrete slab / floor

TÜV Rheinland Germany type tested and monitored

Made of polymer, with telescopic upper

section for continuous height- and level

adjustment.

For installation depth (D)

Ø 90–110, 276–399mm

Ø 125–200, 328–450mm,

Installation area 750×750 mm

With surface water tight cover plate class A 15

made of polymer.

Installation kit with choice of cover.

Backwater valve according to EN 13564 Type 1

with one self-closing flap, can be locked by

hand as an emergency closure.

Note: Can be upgraded to Staufix Type 2.

↗

Accessories: see page 52 – 55

380

L

Single flap backwater valve Staufix

Installation in an exposed wastewater pipe

TÜV Rheinland Germany type tested and monitored

Made of polymer

Backwater valve according to EN 13564 Type 1

with one self-closing flap, can be locked by

hand as an emergency closure.

Note: Can be upgraded to Staufix Type 2.

↗

Accessories: see page 52 – 55

AxB

L

EN 13564 Type 1

Outer diameter

Ø (mm)

Catalogue EN 4.1

L×H in mm

KESSEL AG

Art. no.

720 090.10X

720 100.10X

720 125.10X

720 150.10X

720 200.10X

720 090.10S

720 100.10S

720 125.10S

720 150.10S

720 200.10S

EN 13564 Type 1

Outer diameter

Ø (mm)

Ø90

Ø 110

Ø 125

Ø 160

Ø 200*

With recessed cover for on-site tiling

Ø90

Ø 110

Ø 125

Ø 160

Ø 200*

With black cover

Ø90

Ø 110

Ø 125

Ø 160

Ø 200*

389 × 179

389 × 179

515 × 222

526 × 205

590 × 185

389 × 179

389 × 179

515 × 222

526 × 205

590 × 185

* In-/Outlet Ø 200, hydraulics corresponds to Ø 160

L×H in mm

386 × 230

389 × 230

515 × 306

526 × 306

590 × 306

A×B in mm

193 × 167

193 × 167

263 × 214

263 × 214

263 × 214

Art. no.

720 090

720 100

720 125

720 150

720 200

8

Ø

H

m

i

n

.

4

7

m

a

x

.

1

7

0

8

Ø

H

D

* In-/Outlet Ø 200, hydraulics corresponds to Ø 160
