22

GRUPPI DI RILANCIO

PUMPING STATION

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

CARATTERISTICHE TECNICHE

• Materiale corpo: Ottone CW 617 N

• Materiale guarnizioni: EPDM

• Materiale guscio isolante: EPP

• Dimensione: DN32 (1’’1/4)

• Connessioni interasse 125 mm:

- Ingresso:1”1/2maschiobattutapiana

- Uscita:1”1/4femmina

• Pmax di utilizzo: 8 bar

• Tmax di utilizzo: 110°C

TECHNICAL CHARACTERISTICS

• Body material: CW 617 N brass

• Body gaskets: EPDM

• Body insulation box: EPP

• Dimensions: DN32 (1’’1/4)

• Connections distance between axes 125 mm:

- Inlet:1”1/2maleflatend

- Outlet:1”1/4femaleflatend

• Max working pressure: 8 bar

• Max working temperature: 110°C

CARATTERISTICHE TECNICHE

• Materiale corpo: Ottone CW 617 N

• Materiale guarnizioni: EPDM

• Materiale guscio isolante: EPP

• Dimensione: DN 32

• Connessioni interasse 125 mm:

- Ingresso:1”1/2maschiobattutapiana

- Uscita:1”1/4femmina

• Pmax di utilizzo: 8 bar

• Tmax di utilizzo: 110°C

TECHNICAL CHARACTERISTICS

• Body material: CW 617 N brass

• Body gaskets: EPDM

• Body insulation box: EPP

• Dimensions: DN 32

• Connections distance between axes 125 mm:

- Inlet:1”1/2maleflatend

- Outlet:1”1/4femaleflatend

• Max working pressure: 8 bar

• Max working temperature: 110°C

Da abbinare al servomotore 9562SERV

5534G

5534G3P

Gruppo di rilancio

Gruppo di miscelazione per

servomotore (non compreso)

Heating circulation pumps

Mixing unit for servomotor (not

provided)

Senza circolatore/ without

pump

Grundfos UPML 32-105

AUTO

ErP READY

To be combined with servomotor 9562SERV

316 0093

316 0095

C22 1/1

C22 1/1

Senza circolatore/ without

pump

Grundfos UPML 32-105

AUTO

ErP READY

316 0097

316 0099

C22 1/1

C22 1/1

481
