MISCELATORI TERMOSTATICI

THERMOSTATIC MIXING VALVES

CARATTERISTICHE TECNICHE

The kit includes: 3 tails, 3 nuts and 3 gaskets

• Range di temperatura: 30÷65°C

• Pressione max di esercizio: 10 bar

• Temperatura max di ingresso: 90°C

• Materiale corpo: ottone CW625N

• Materiale manopola: PA

• Portata minima per un corretto funzionamento:

12 l/min. (1”1/4) - 15 l/min. (1”1/2) - 25 l/min. (2”) - 30 l/min. (2”1/2)

TECHNICAL CHARACTERISTICS

• Range of temperature (°C): 30÷55°C

• Max operating pressure: 10 bar

• Max operating temperature: 90°C

• Material: brass CW625N

• Setting knob: PA

• Minimum flow rate for a correct operation:

12 l/min. (1”1/4) - 15 l/min. (1”1/2) - 25 l/min. (2”) - 30 l/min. (2”1/2)

RESISTENTE ALLA DEZINCIFICAZIONE

150 1013

150 1014

150 1015

150 1016

1”1/4 F x 1” M

1”1/2 F x 1”1/4 M

2" F x 1"1/2 M

2"1/2 F x 2" M

C10 1/15

C10 1/10

C10 1/10

C10 1/5

4738G

1521CPKIT

Miscelatore termostatico per

impianti sanitari - alte portate

Kit bocchettoni

Thermostatic mixer for sanitary

installations - high flow

Union kit

Il kit comprende: 3 codoli, 3 dadi girevoli, 3 guarnizioni

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

4737-4738

ESEMPIO DI INSTALLAZIONE

4739

EXAMPLE OF ISTALLATION

DEZINCIFICATION RESISTANT

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

320 0046

320 0047

320 0049

320 0051

1” 1/4

1” 1/2

2"

2” 1/2

C22 1/8

C22 1/8

C22 1/3

C22 1/3

22

REGOLATORE TERMOSTATICO MULTIFUNZIONE

MULTIFUNCTION THERMOSTATIC REGULATOR

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

Codice

Code

Tipo

Size

Prezzo €

Price €

Cat.

Cat.

Conf.

Unit/Box

RESISTENTE ALLA DEZINCIFICAZIONE

DEZINCIFICATION RESISTANT

473 0005

1/2"

473 0006

3/4"

RESISTENTE ALLA DEZINCIFICAZIONE

4733

4734

Regolatore termostatico

multifunzione per circuiti di

ricircolo acqua calda sanitaria

Multifunction thermostatic

regulator for domestic hot water

recirculation circuits

Regolatore termostatico

multifunzione per circuiti di

ricircolo acqua calda sanitaria

con disinfezione termica

comandata da attuatore

Multifunction thermostatic

regulator for domestic hot

water recirculation circuits with

actuator controlled thermal

disinfection

C22

1/6

C22

1/6

DEZINCIFICATION RESISTANT

473 0007

1/2"

473 0008

3/4"

C22

1/8

C22

1/8
